Pwm 0-10v Digital To Analog Signal Tranformer Converter Module Mach3 Mcu Plc

US $3400

Guangzhou , China
May 28th

Open on mobile:
QR code

PWM 0-10V Digital to Analog Signal Tranformer Converter Module MACH3 MCU PLC DESCRIPTION Description: PWM digital signals into analog signals from 0 to 10V. Convert PWM digital signal into 0 to 10 v analog signals. Power Input Range: 12V-30V (Power requirements: more than 100MA) Signal interface switch can be used for PLC or other industrial control board. PWM Reception frequency range: 1 KHZ - 3 KHZ. Current output capacity: 10MA. Resolution: 0.1V. Usage: by adjusting the potentiometer board, can match the calibration of PWM signals of different frequency pulse PWM signal input level range: 4.5V to 10V peak to peak level, jumper inserted at 5V. This type signal mainly for conventional industrial control card (such as MACH3 board), for 5V the CPU interface. 12 to 24V peak to peak level, jumper inserted at 24V. This type signal mainly for conventional PLC interface Note: When the signal input port is not connected, the output port gives 10V. The first time when we power on this module, we better calibrate it: find a 50% duty ratio signal, connect to DIN-, DIN+, the amplitude matches corresponding jumper. When frequency is at 1kHz ~ 3kHz, use a multi-meter to test AO, GND. The meter should be showing around 5V. We adjust the potentiometer on the converter module to make multi-meter shows 5V sharp. After this is done, we have calibrated and matched pulse signal with this converter module. The module has a definition of 0.1V. Output current 10mA. If duty ratio is in opposite to voltage, we can select or un-select PWM output pin STEP LOW / ACTIVE in MACH3 software PAYMENT We Only Accept Paypal on Ebay. For specific requirements, please feel free to contact us. SHIPPING Shipping: Packages are sent from overseas, please expect lengthy custom delays if you choose to use default shipping service. Shipping to some countries is slow. That depends on your local postal service. Most orders to USA take about 7-20 days using epacket(USPS first-class service with tracking#). Shipping to most other countries takes about 10-30 days via Economy Int'l Airmail without tracking#. In rare case, it can take up to 40 days. It depends on your location and local postal service(e.g., Russian Postal service is slow), as well as the weather condition along the shipping. We don't take responsibility if you submit wrong address. Here's an approx delivery time to some countries: Please contact us if you need a tracking# or express shipping service. TERMS OF SALE If you are facing with troubles below, please contact us as soon as you can Defective or Wrong: full refund or send you a new replacement Missing: new package arranged, or partial refund Dislike: full refund after we received your item (buyer undertakes return shipping fee) ABOUT US Our working time is 08:30-17:30 from Monday to Friday in Beijing Time. Because of the time difference, we may not reply your email immediately. All emails will be replied in 24 hours, please understand that. We devote to making the best service for you. We look forward to serving you. Any questions, please contact us via our ebay email. Your emails are warmly welcomed. CONTACT US Consumers' satisfaction is our first priority and pursuit . We promise to solve your problem in a good way . We consider neutral and negative feedbacks as a SHAME. So please never give us a neutral or negative feedback before communicating with us .
