Pwm Signal Frequency Generator Adjustable Module Duty Cycle Lcd Display Quality

US $34.51

Shanghai, China
Aug 26th

Open on mobile:
QR code

PWM Signal Frequency Generator Adjustable Module Duty Cycle LCD Display Quality Description: XY-KPWM signal generator is a device that provides electrical signals at a variety of frequencies, square wave, and output levels.It is used as a signal source or excitation source for testing.Widely used in production practice and technology. Features: 1>.With outer casing 2>.LCD high definition display 3>.Support UART 4>.Support frequency adjustment 5>.Support duty cycle adjustment 6>.High precision detection 7>.Support power-down memory function 8>.1-Channel PWM output 9>.Dual Work Mode 10>.Knob supports lock function to avoid misoperation 11>.Support enable output 3.Parameters: 1>.Product name: XY-KPWM PWM Signal Generator; 2>.Model: XY-KPWM; 3>.Work Voltage:DC 3.3V-30V; 4>.Frequency range(Normal mode):1Hz~150KHz; 5>.Frequency range(Precise mode):1Hz~15KHz; 6>.Frequency accuracy:2%; 7>.Duty cycle accuracy:1% at Normal mode; 8>.Duty cycle accuracy:0.1% at Precise mode; 9>.Duty cycle range:0.00%-100%; 10>.Output Current:About 5-30mA; 11>.Output amplitude:Same to input voltage; 12>.Work Temperature:-40°~85°; 13>.Work Humidity:0%~95%RH; 14>.Size:79*43*37mm; 4.Frequency set range: There is two work modes so it has two frequency ranges. Normal mode:Frequency range 1Hz~150KHz.Duty cycle range 000%-100%.Duty cycle accuracy 1%. Precise mode:Frequency range 1Hz~15KHz.Duty cycle range 0.00%-100%.Duty cycle accuracy 0.1%. Enter the settings interface when short press rotary switch in the normal running status to select frequency range.Rotary potentiometer to set frequency value. Keep press rotary switch for 10second to switch Normal mode and Precise mode. Keep press for 5second to locking parameters to protect the parameters from being modified. Pay attention to the position where the decimal point moves when rotary potentiometer.. Display 'XXX'.No decimal point,The minimum frequency is 1Hz.The frequency range is 1Hz ~ 999Hz. Display 'X.XX'.The decimal point is the penultimate, The minimum frequency is 0.01KHz.The frequency range is 1.00KHz ~ 9.99KHz. Display 'XX.X'.The decimal point is the third last,The minimum frequency is 0.1KHz.The frequency range is 10.0KHz ~ 99.9KHz. Display 'X.X.X'.The decimal point is fully lit,The minimum frequency is 1KHz.The frequency range is 1KHz ~ 150KHz. For Example: Display '100' means PWM output frequency is 100Hz; Display '1.91' means PWM output frequency is 1.91KHz; Display '52.1' means PWM output frequency is 52.1KHz; Display '1.3.4' means PWM output frequency is 134KHz; 5.Duty cycle set range: Short press potentiometer to select set duty cycle and rotary potentiometer to set duty cycle value. 6.Use steps: 1>.Connect to power supply; 2>.Press rotary switch for 10second to switch Normal mode and Precise mode; 3>.Short press rotary switch to set frequency and change value by rotating switch; 4>.Press rotary switch for 2second to set duty cycle; 5>.Keep press for 5second to lock set parameters; 6>.Test; 7>.Press button 'ON/OFF' to turn on or off PWM output; 8>.Remove power and connect load to use module. 7.Application: 1>.Square wave signal generator, generating square wave signal for experimental development; 2>.Used to generate a square wave signal that controls the motor driver; 3>.Generate adjustable pulses for use by the MCU; 4>.Dimmer If you have more questions about the product, feel free to contact me, I would be happy to help!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	5701861957
Certification	RoHS
Country/Region of Manufacture	China
DIY Supplies	ELECTRICAL
MPN	5701861977
Origin	CN(Origin)
Brand	Signal
UPC	Does not apply
