Pzem-022 Ac Digital Display Meter Power Energy Voltage Current Test Closed

C $26.86

suzhou, China
Aug 7th

Open on mobile:
QR code

Product Description PZEM-022 AC Digital Display Meter Power Energy Voltage Current Test Closed Product description: Electrical parameter measurement function (voltage, current, active power, energy, frequency, power factor) Overload alarm function (exceeding the power alarm threshold, backlight and power flashing alarm). Power alarm threshold preset function (power alarm threshold can be set). You can use the button to reset the energy. Store data when power is off. Large screen LCD Backlight function. Product parameters: Model: PZEM-022 Working voltage: 80~260VAC Test voltage: 80~260VAC Current: 100A Rated power: 100A / 22000W Working frequency: 45-65Hz Measurement accuracy: 1.0 level Size: 9 * 5 * 2.5cm / 3.5 * 2 * 1in Cable length: 19cm / 7.5in Weight: about 110g / 3.9oz Appearance and key functions: One, display interface The display interface is a large LCD screen, which can display six parameters at the same time. Two, display format 1. Power: Test range: 0~22000W, start measurement power: 0.2W 10W display format: 1.00~9.99W 100W display format: 10.0~99.9W 1000W display format: 100~999W 10000W Display format: 1.00~9.90kW 10000W Display format: 10.0~22.0kW 2. Energy: Test range: 0~999kWh 1kWh Display format: 0999Wh 10kWh Display format: 1.009.99kWh 10kWh Display format: 10~999kWh 3. Voltage: Test range: 80~260V Display format: 80~260V 4. Current: Test range: 0~100A, start measuring current: 0.001A 10A display format: 0.0009.000A 10A Display format: 10.00~99.99A 5. Frequency: Test range: 45~65Hz Display format: 45~65Hz 6. Power factor: test range: 0~1PF Display format: 0.00~1.00PF Key Function: 1. Backlight control Short press this key to turn on or off the backlight. The backlight has a memory function and can store the on or off status when the power is off. 2. Reset energy Step 1: Press and hold the key for 5 seconds until the energy value flashes, then release the key. Step 2: Short press the key again, then clear the energy value and exit the reset flashing state. Step 3: If there is no operation on the button within 5 seconds, it means that the energy value has not been cleared and the reset state will be exited. 3. Set the power alarm threshold Step 1: Press and hold the key until the LCD screen displays "SET CLr", then release the key to enter the setting state Step 2: The power casement displays the current power alarm value, and the last digit starts to flash, and then short press the plus sign 1, if there is no operation for more than 3 seconds, the position of the digit will be automatically switched. The setting method is the same as described above. Step 3: After the setting is completed, press and hold this key for 5 seconds to automatically store and exit. The active power threshold range is 0.0~2.5kW. Package list: 1 * AC multifunctional digital meter 1 *Closed CT Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours. On 07-Aug-21 at 08:25:17 EDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	unbrandeed
Current	100A
MPN	Does Not Apply
Rated power	100A / 22000W
Type	AC multifunctional digital meter
Working frequency	45-65Hz
Package Contents	AC multifunctional digital meter kit
Measurement accuracy	1.0 level
Country/Region of Manufacture	China
Size	9 * 5 * 2.5cm / 3.5 * 2 * 1in
Model	PZEM-022
Cable length	19cm / 7.5in
Working voltage	80~260VAC
Weight	about 110g / 3.9oz
Test voltage	80~260VAC
UPC	Does not apply
