(Qty 1) Collet Chuck Assembly - RMC 2324A-250 (C-1010A, TC-1010, HT-1010), US $29 – Picture 0
(Qty 1) Collet Chuck Assembly - RMC 2324A-250 (C-1010A, TC-1010, HT-1010), US $29 – Picture 0

(qty 1) Collet Chuck Assembly - Rmc 2324a-250 (c-1010a, Tc-1010, Ht-1010)

US $29

  • Tecumseh, Michigan, United States
  • Oct 25th
Open on mobile:
QR code
For Sale - One new Collet Chuck Assembly (Quantity of 1 Piece) Part No. 2324A-250 Made in USA by Roesch Manufacturing Co. LLC This is a two piece style collet chuck for portable pneumatic grinders. The two piece style means that it consists of a collet body that is tapered and slotted, which, when the mating nut is tightened, clamps on the tool shank. This style does not use any other collet internally. It has a fixed bore size that holds 1/4" shank tools. These are new parts that were prototypes for an OEM customer.  These were premium parts that were designed with slot relief holes at the base of the four slots.  They are made from heat treated alloy steel with a black oxide finish. Specifications: OD dia. = 7/8"  -   Length = 2 1/2" There are 3/4" wrench flats on both the nut and body Mounting is 3/8"-24 approximately 1 1/16" deep with a thread recess 1/2" deep Bore is 1/4" fixed capacity The thread between the body and nut is 5/8"-24
