(Qty 100) AWL6153 ANADIGICS 2.4GHz WLAN Power Amplifier 54Mbps IEEE 802.11g, US $87 – Picture 0
(Qty 100) AWL6153 ANADIGICS 2.4GHz WLAN Power Amplifier 54Mbps IEEE 802.11g, US $87 – Picture 0

(qty 100) Awl6153 Anadigics 2.4ghz Wlan Power Amplifier 54mbps Ieee 802.11g

US $87

  • ATHENS, Greece
  • Jun 9th
Open on mobile:
QR code
Great 2.4GHz RF boost!!  LONG RANGE!!! Easy to use!! No external circuits are required for RF impedance matching AWL6153 Description:  2.4 GHz Wireless LAN Power Amplifier Module     The ANADIGICS AWL6153 WLAN Power Amplifier is an easy to use module that delivers high level of linearity and efficiency for high data rate applications. Designed for the 2.4 GHz WLAN standards, it supports the 54 Mbps data rates specified in IEEE 802.11g. Requiring a single +3 V to +5 V supply and a reference voltage input, the AWL6153 reduces system power consumption by offering a low leakage current while the amplifier is shut down. No external circuits are required for RF impedance matching, thus reducing component costs and making it easy to incorporate the device into new designs. The AWL6153 is manufactured using an advanced InGaP HBT technology that offers state-of-the-art reliability, temperature stability and ruggedness. It is offered in a 4 x 4 x 1.4 mm surface mount module optimized for a 50 ? system. FeaturesInGaP HBT Technology < 3.5% EVM at +25 dBm Output Power (+5 V Supply), with 802.11g Modulation at 54 Mbps Data Rate < 3% EVM at +21 dBm Output Power (+3.3 V Supply), with 802.11g Modulation at 54 Mbps Data Rate +3 V to +5 V Supply High Efficiency 50?- Matched RF Ports for Reduced External Component Count 4 mm x 4 mm x 1.4 mm Surface Mount Module, Materials Set Consistent with RoHS Directives. SpecificationsFrequency (GHz):  2.4 to 2.5 Error Vector Magnitude [EVM] :  2.5% @ Pout = +21 dBm 3% @ Pout = +25 dBm Gain (dB) Typ:   29.5  30.5 Supply Current (mA) Typ:  b: 250 @ Pout = +25 dBm (3.3V) 350 @ Pout = +28 dBm (5V) g: 160 @ Pout = +21 dBm (3.3V) 240 @ Pout = +25 dBm (5V) Supply Voltage (V):   3.0 to 5.0 Tx OP1dB (dBm) typ:   28  31 Package (mm) :   4 x 4 x 1.4 Related Product Information Product Datasheet  298.93 KB ANADIGICS Brochure
