Quadtech Hybrid 2000 Ac/dc/ir/dcr Safety Analyzer

US $1,999.99

Loveland, Colorado, United States
Jan 29th

Open on mobile:
QR code

Other Add my Store to your Favorites and receive my email newsletters about new items and special promotions! General Interest Quadtech Hybrid 2000 AC/DC/IR/DCR Safety Analyzer Description The only hipot and 4 wire resistance meter on the market. Why Buy? Perform hipot & contact resistance testing with one instrument Automatic switching for multi-point testing Monitor resistance while checking intermittent connections Insulation resistance testing up to 5000V DC Features New and improved DC resistance 2 or 4 wire Substep function allows for secondary tests to be performed after failure DC resistance temperature compensation DCR Balance AC Dielectric Withstand Voltage 50 to 5000VAC, Current to 30mA DC Dielectric Withstand Voltage 50 to 6000VDC, Current to 10mA IR Measurements from 1M? to 50G?, Test Voltage 50 to 5000VDC DC Resistance Measurements from 50m? to 100k? Real and Total Current Measurement Built-in Scanner with 8 HV Output Channels for Multi-Point Testing Programmable Hi/Lo Limits for Pass/Fail Testing Ability to Perform Multiple Tests in Sequence Internal Storage and Recall of 50 Test Setups, 20 Steps Each Programmable Ramp, Dwell, Test and Fall Times Open/Short Circuit Check to Ensure the Device is Connected Pause Mode Allows the Operator to Change Device Connection & Continue Front Panel Lockout Prevents Changes to the Test Setup Automatic Offset to Zero Out Residual Current Ground Fault Interrupt (GFI) for auto shutdown if current imbalance >0.5mA RS232 Interface Included Standard Built-In Operator Prompted Software Calibration Routine CE Marked PAYMENT: Payment is due upon receipt of your final invoice. We accept PayPal and all major Credit Cards. Credit card payments are processed directly through the PayPal system. We do not collect or store credit card or personal information. COMBINED SHIPPING: We always combine shipping. If your items have not been combined into a single invoice please contact us. SHIPPING: We ship using UPS and the US Postal service. We will allow customers to use their own UPS or FedEx account for special shipping situations. It is your responsibility to provide a deliverable ship to address at the time of purchase. Most orders are shipped same day or next day with the exception of freight. We ship M-F inclement weather and holidays are the exception . Overnight Shipments: We can accommodate most requests. It is recommended that you make your purchase and payment before 3 PM EST. We do not receive regular FedEx pickups, so if you need FedEx service please call or order early. Overseas Shipments: We ship USPS Priority Mail International in most cases. There are weight and size restrictions to all countries using USPS Priority mail and any other postal service. We do not ship first class mail. Delivery times vary and we cannot guarantee delivery dates. Overseas Freight: Some items will require a special certified crate be made prior to shipment. This cost will be added to any freight charges. *Overseas shipping is quoted as a door to door service. The shipping price does not include taxes (VAT), terminal fees, import fees or any other fees levied by the receiving country. If you are not aware of these additional costs you should contact your local government for more information before your purchase. * USA Freight Shipments: Items marked over 150 lbs. must be shipped freight. Residential delivery is more expensive than delivery to a commercial address. Freight shipments cannot be sent to an address with an apartment number. A valid phone number is also required prior to shipment. QUESTIONS: If you do have any questions about our listed items please use the eBay system to contact us. The more information you can provide the easier it will be to help you. If your require technical support we will always direct you to the manufacturer.. We are a salvage company and 95% of our inventory is listed on eBay. we are not a dealer for any product. CONTENT: On occasion, we do have to rely on 3rd party sources for information. We cannot guarantee the accuracy of the information we have provided in this or any other listing. We suggest you contact the manufacturer directly if you have any technical questions regarding products we have for sale. GUARANTEE: If you are not 100% satisfied with your purchase we have an easy refund policy. No questions asked. Just pay for return shipping and send the item back to us within 14 days of receipt. Item must be unmodified; all parts must be returned in the original packaging. Your satisfaction is important to us. The Automation Wholesale Team © Copyright Automation Wholesale | All Rights Reserved | eBay Template Design inkfrog terapeak inkFrog Analytics
