R&s Rohde & Schwarz Nrp-z11 10mhz-8ghz With Manual

US $850.00

Denver, Colorado, United States
Jan 29th

Open on mobile:
QR code

Being offered is a ROHDE & SCHWARZ model NRP-Z11 Power Sensor, 10MHZ-8GHZ It is in excellent condition and includes the original Manual. Description Three-path diode power sensor R&S®NRP-Z11 is suitable for numerous applications because they support continuous average, burst average, timeslot average, gate average and trace measurements. Featuring outstanding performance and high measurement speed and accuracy, the sensors can be used to perform precise average power measurements on modern wireless standard signals such as LTE, 3GPP, GSM, WiMAX™ and WLAN. For detailed analysis of GSM signals, for example, the sensors offer additional measurement functions such as the timeslot mode and trace mode with a video bandwidth of 100 kHz. Key Facts Measurement range: -67 dBm to +23 dBm (200 pW to 200 mW) Frequency range: 10 MHz to 8 GHz N connector Operation with R&S®NRP2 base unit or via USB on a Laptop/PC 90 dB dynamic range for CW and modulated signals Innovative three-path diode power sensor with enhanced inter-range performance Continuous average, burst average, timeslot average, time gating and trace mode supported (video bandwidth100 kHz) Automatic burst detection and acquisition Up to 1500 measurements/s (buffered mode) Low sensitivity to harmonics True universal power sensor for a vast number of applications Specifications Three-Path Diode Power Sensors Frequency range Power measurement range; maximum input power Impedance matching (SWR) Rise time, video BW Uncertainty for power measurements at +20 °C to +25 °C (1) absolute (in dB) (2) relative (in dB) R&S®NRP-Z11, N connector 10 MHz to 8 GHz 200 pW to 200 mW (–67 dBm to +23 dBm) max. 400 mW (AVG)/ 1 W (PK, 10 ?s) 10 MHz to 2.4 GHz: <1.13 >2.4 GHz to 8.0 GHz: <1.20 <8 µs, >50 kHz (1) 0.047 to 0.083 (2) 0.022 to 0.066 R&S®NRP-Z21, N connector 10 MHz to 18 GHz 200 pW to 200 mW (–67 dBm to +23 dBm) max. 400 mW (AVG)/ 1 W (PK, 10 ?s) 10 MHz to 2.4 GHz: <1.13 >2.4 GHz to 8.0 GHz: <1.20 >8.0 GHz to 18.0 GHz: <1.25 <8 µs, >50 kHz (1) 0.047 to 0.128 (2) 0.022 to 0.110 R&S®NRP-Z22, N connector 10 MHz to 18 GHz 2 nW to 2 W (–57 dBm to +33 dBm) max. 3 W (AVG)/ 10 W (PK, 10 ?s) 10 MHz to 2.4 GHz: <1.14 >2.4 GHz to 8.0 GHz: <1.20 >8.0 GHz to 12.4 GHz: <1.25 >12.4 GHz to 18.0 GHz:<1.30 <8 µs, >50 kHz (1) 0.079 to 0.178 (2) 0.022 to 0.112 R&S®NRP-Z23, N connector 10 MHz to 18 GHz 20 nW to 15 W (–47 dBm to +42 dBm) max. 18 W (AVG)/ 100 W (PK, 10 ?s) 10 MHz to 2.4 GHz: <1.14 >2.4 GHz to 8.0 GHz: <1.25 >8.0 GHz to 12.4 GHz: <1.30 >12.4 GHz to 18.0 GHz: <1.41 <8 µs, >50 kHz (1) 0.078 to 0.199 (2) 0.022 to 0.110 R&S®NRP-Z24, N connector 10 MHz to 18 GHz 60 nW to 30 W (–42 dBm to +45 dBm) max. 36 W (AVG)/ 300 W (PK, 10 ?s) 10 MHz to 2.4 GHz: <1.14 >2.4GHz to 8.0 GHz: <1.25 >8.0 GHz to 12.4 GHz: <1.30 >12.4 GHz to 18.0 GHz: <1.41 <8 µs, >50 kHz (1) 0.078 to 0.222 (2) 0.022 to 0.110 R&S®NRP-Z31, 3.5 mm connector 10 MHz to 33 GHz 200 pW to 200 mW (–67 dBm to +23 dBm) max. 400 mW (AVG)/ 1 W (PK, 10 ?s) 10 MHz to 2.4 GHz: <1.13 >2.4 GHz to 8.0 GHz: <1.20 >8.0 GHz to 18.0 GHz: <1.25 >18.0 GHz to 26.5 GHz: <1.30 >26.5 GHz to 33.0 GHz: <1.35 <8 µs, >50 kHz (1) 0.051 to 0.137 (2) 0.022 to 0.118 R&S®NRP-Z41, 2.92 mm connector 50 MHz to 40 GHz 200 pW to 100 mW (–67 dBm to +20 dBm) max. 200 mW (AVG)/ 2 W (PK, 10 ?s) 50 MHz to 2.4 GHz: <1.13 >2.4 GHz to 8.0 GHz: <1.20 >8.0 GHz to 18.0 GHz: <1.25 >18.0 GHz to 26.5 GHz: <1.30 >26.5 GHz to 33.0 GHz: <1.35 >33 GHz to 40.0 GHz: <1.37 <8 µs, >50 kHz (1) 0.074 to 0.150 (2) 0.028 to 0.137 R&S®NRP-Z61, 2.4 mm connector 50 MHz to 50 GHz 200 pW to 100 mW (–67 dBm to +20 dBm) max. 200 mW (AVG)/ 2 W (PK, 10 ?s) 50 MHz to 2.4 GHz: <1.13 >2.4 GHz to 8.0 GHz: <1.20 >8.0 GHz to 18.0 GHz: <1.25 >18.0 GHz to 26.5 GHz: <1.30 >26.5 GHz to 33.0 GHz: <1.35 >33 GHz to 40.0 GHz: <1.37 >40 GHz to 50.0 GHz: <1.40 <8 µs, >50 kHz (1) 0.074 to 0.191 (2) 0.028 to 0.166

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Good condition with Manual”
