R-k Electronics Go- No Go Sensing Relay, Mdl# Csr-1-18-5.0-4.5

US $79.00

Oshkosh, Wisconsin, United States
Jan 29th

Open on mobile:
QR code

CSR Go-No Go AC Current Sensing Relay Operation AC Current Sensing The CSR generates its own operating power supply from the monitored current line. No external power supply is needed. A current greater than the pick-up current is required to energize the output relay. The output relay will stay energized until the current in theline being monitored drops below the drop-out current level for the CSR. Specifications Electrical Input Supply Voltage: None Required Pick-Up Range: 5.0 Amps ±12% Power Up Delay: 0.1Sec. Fixed Drop-Out Range: 4.5 Amps ±7% Drop-Out Delay: None Frequency: 50/60Hz Maximum Current: 200 Amps LRA, 15 Seconds max. 64 Amps FLA, Continuous Reset: Automatic Output Rating @ 25°C: 10 Amps @ 250VAC, 30VDC (UL) 300W (D.C.), 2500VA (A.C.) Max.switch 6,000 Full Load Electrical Cycles (UL) 100,000 Full Load Electrical Cycles 20,000,000 Mechanical Cycles Physical Maximum Load Wire Diameter: 0.560” Dia. Mounting: Surface or DIN Rail Termination:#16 Stranded Wire Leads Packaging: Dust Cover Weight: 18 Oz. Ambient Temperatures Operating: 0°C to 55°C Storage: -10°C to 85°C hing power (resistive

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	R-K Electronics
MPN	CSR-1-18-5.0-4.5
Model	CSR-1-18-5.0-4.5
