Radioshack 5mm Green Led 276-0022

US $5.99

  • Sherman, Texas, United States
  • Jan 29th
Green LED Lamp with 5MM diameter and a diffused lens: Parameter Conditions Forward voltage: max 3.0, IF=20mA Reverse breakdown voltage: min 5.0, IR=100 uA Luminous intensity: min 40mcd, Typ 70mcd, IF=20mA Peak wavelength: Typ 570nm, IF=20ma Spectral line halt width: Typ 20nm, IF=20ma Absolute Maximum Ratings Power dissipation: @ Ta=25°C - 90mW Forward current: DC (IF) 30mA Reverse voltage: 5V Operating and storage temp: -55-100°C Lead soldering temp: (1/16" from body) 260°C for 5 sec T-1-3/4 size (5mm) Green lens color Viewing angle of 30° 10 mA current max Typical voltage 2.2V, with a maximum of 2.4V Two per package Please contact us through email with any questions. We will answer them as best and quickly as we can. As always, thanks for looking and have a great day!  Check out our other eBay listings.  Powered by SixBit's eCommerce Solution
