Rapidrun 60018 Vga + 3.5mm + Rca A/v 1.5 Ft. Flying Lead 183-851

US $80

Dayton, Ohio, United States
Feb 16th

Open on mobile:
QR code

Product Features • Designed for use with RapidRun Multi-Format runner cables • Compatible with RapidRun Multi-Format VGA, 3.5mm, Composite Video and RCA Stereo Audio wall plates and flying leads • 28 AWG and 24AWG conductor construction Product Description RapidRun® is designed to be the standard for in-wall audio/video. Using pre-terminated Break-away flying leads and wall plates with an in-wall runner ensures flexible, efficient, high quality connections for all types of equipment, with no field terminations. Ideal for educational and institutional installations, this flying lead sends PC video, 3.5mm stereo audio and RCA composite audio/video over one cable. It is commonly used on the display (projector) end of classroom setups with the corresponding wall plate used at the teacher's station. 3 Coax Conductors • Impedance - 75 ± 5? • Capacitance - 71 ± 2pF/ ft nom • Velocity of Propagation - 78 ± 1% • DC Resistance - 237 ± 10?/km • Dielectric Strength - 500VAC/1 minute min. • Insulation Resistance (500V) - 10M?/KM • Attenuation (dB/6m) - Red Coax - Green Coax - Blue Coax 1MHz - 0.1464 0.1376 0.1419 10MHz - 0.86 0.97 0.4058 100MHz - 2.98 3.23 1.259 200MHz - 4.45 4.87 1.823 500MHz - 6.72 7.75 3.0028 700MHz - 9.95 12.01 3.64 1000MHz - 13.20 17.52 4.5923 3 Twisted Pair Conductors • DC Resistance - 93.25?/m at 20°C • Dielectric Strength - 750VAC/minute min. • Insulation Resistance - 100Mohm/KM at 20°C Physical Characteristics • Voltage Rating - 30V • Temperature Rating - 80°C • Temperature Range - -25° ~ 80°C • Minimum Bend Radius - 90mm • Approvals - RoHS Compliant • Warranty - Lifetime • Package Type - Polybag Conductor (Qty. 3) • Conductor Type - 28AWG 7/0.127, Tinned Copper • Dielectric - Minimum Avg. Thickness: 1.57 mm, Foam PE • Shield - Spiral 90% Coverage, Tinned Copper • Insulation - Minimum Avg. Thickness: 0.23 mm, PVC: (1) red, (1) blue, (1) green Conductor (Qty. 3 twisted pair + 2 conductors) • Conductor Type - 24AWG 7/0.2, Tinned Copper • Foil Shield - Aluminum, 100% coverage • Insulation - Minimum Avg. Thickness: 0.23mm, PVC [BOverall Cable[/B] • Shield - Aluminum Mylar Wrap – 100%, Braided Shield 24/8/0.12, 85% Coverage, Tinned Copper • Jacket - Minimum Avg. Thickness – 0.76mm, Matte PVC, Orange Heat Shrink VGA Connector (Qty. 1) • Connector Type - HD15 • Gender - Male • Contact Material - Brass, 3?m Gold Plating • Insulation - Black PBT Note - Pin 9 is not loaded. 3.5mm Connector (Qty. 1) • Connector Type - 3.5mm Stereo • Gender - Male • Contact Material - Brass, 3?m Nickel Plating • Insulation - Black PBT RCA Connector (Qty. 3) • Connector Type - RCA • Gender - Male • Contact Material - Brass, 3µm Gold Plating • Insulation - White PBT RapidRun Din Connector (Qty. 1) • Connector Type - DIN 15 pin • Gender - Male • Contact Material - Brass, 3µm Gold Plating • Insulation - Black PBT Product Specifications Color : Black UPC : 757120600183 Warranty : Lifetime Vendor : C2G Weight : 0.410 LB Length : 1.50 Foot

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RapidRun
MPN	60018
Model	60018
Country/Region of Manufacture	China
