Rayco Vacuum Clamping Kit And Manifold Fixture Plate

US $740

  • Morrisville, North Carolina, United States
  • Nov 6th
Open on mobile:
QR code
Rayco Vacuum Fixture Plate Kit. This is a great Modular Fixture Kit for measuring your parts on an Optical Comparator of Video Measuring Machine. Comes with the Acrylic 7" x 9"  Plate with 9-Port Manifold, Suction Cups, Vacuum Pump, 9 Air Lines, Tension Springs, Standoffs and Slide Bases. The Plate has 4 holes that were enlarged for a special application, see above. The thread sizes in the Fixture Plate is 1/4-20, with .500" spacing. The plate thickness is .750". This kit comes with everything pictured above.
