Rca/idi 2n4036 Transistor Gp Bjt Pnp 65v 1a 3-pin To-5 Old Gold

US $6.95

Stanton, California, United States
Aug 3rd

Open on mobile:
QR code

RCA/IDI 2N4036 Transistor GP BJT PNP 65V 1A 3-Pin TO-5 OLD GOLD NEW OLD STOCK LOT 30968 F27 Characteristic Specifications SEMICONDUCTOR MATERIAL SILICON INTERNAL CONFIGURATION JUNCTION CONTACT VOLTAGE RATING IN VOLTS PER CHARACTERISTIC -90.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND -7.0 MAXIMUM EMITTER TO BASE VOLTAGE, STATIC, COLLECTOR OPEN AND -65.0 MAXIMUM COLLECTOR-TO-EMITTER, SUBSTAINING VOLTAGE, BASE OPEN-CIRCUITED AND -85.0 MAXIMUM COLLECTOR-TO-EMITTER SUBSTAINING VOLTAGE, RESISTANCE BETWEEN BASE AND EMITTER AND -85.0 MAXIMUM COLLECTOR-TO-EMITTER SUBSTAINING VOLTAGE, WITH VOLTAGE BETWEEN BASE AND EMITTER CURRENT RATING PER CHARACTERISTIC 0.50 AMPERES MAXIMUM BASE CURRENT, DC AND 1.00 AMPERES MAXIMUM COLLECTOR CURRENT, DC POWER RATING PER CHARACTERISTIC 7.0 WATTS MAXIMUM TOTAL DEVICE DISSIPATION MAXIMUM OPERATING TEMP PER MEASUREMENT POINT 200.0 DEG CELSIUS JUNCTION INCLOSURE MATERIAL METAL ELECTRODE INTERNALLY-ELECTRICALLY CONNECTED TO CASE COLLECTOR JOINT ELECTRONIC DEVICE ENGINEERING COUNCIL/JEDEC/CASE OUTLINE DESIGNATION TO-5 MOUNTING METHOD TERMINAL TERMINAL LENGTH 1.500 INCHES MINIMUM TERMINAL TYPE AND QUANTITY 3 UNINSULATED WIRE LEAD OVERALL LENGTH 0.240 INCHES MINIMUM AND 0.260 INCHES MAXIMUM OVERALL DIAMETER 0.335 INCHES MINIMUM AND 0.370 INCHES MAXIMUM FEATURES PROVIDED HERMETICALLY SEALED CASE SPECIAL FEATURES JUNCTION PATTERN ARRANGEMENT: PNP MANUFACTURERS CODE 54418 MFR SOURCE CONTROLLING REFERENCE M59-89

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Maximum Collector-Emitter Saturation Voltage	-3 V
Series	2N4036
Collector-Emitter Voltage	65 V
Type	PNP BJT
Maximum Base-Emitter Voltage	-3 V
Transistor Category	Small Signal Transistor
Mounting Style	Through-Hole
Maximum DC Collector Current	1 A
Maximum Base-Emitter Saturation Voltage	-2 V
MPN	2N4036
Maximum Collector-Base Voltage	5 V
Brand	RCA
Number of Pins	3
Package/Case	TO-5
