Rdc6442g Laser Machine Control System/laser Machine Control Card

US $490.00

???, ???, China
Feb 27th

Open on mobile:
QR code

Ruida laser engraving cutting control system RDC6442G RDC644XG system is the Core Technology developed the latest generation laser engraving / cutting control system , the control system has better hardware stability, with better resistance to high pressure , anti-static characteristics of interference . Based on 3.5 -inch color screen human-machine operating system has a more friendly user interface and more powerful . The controller includes better and more superior motion control functions , large file storage , compatibility stronger dual independently adjustable laser power control interface , compatibility stronger U disk driver, multiple generic / private IO control and communicate with the PC supports Ethernet communications and automatic optional USB communications and so on. Technical parameters Digital laser control signals (1) TTL level output , 50mA drive capability (2) PWM Adjustable Frequency 2K ~ 50K (3) PWM duty cycle is adjustable from 1% to 99% Motor control signal OC output , 300mA drive capability Maximum motor control pulse frequency 500KHZ Maximum transfer rate USB 12M, the longest distance 5 m Straight line / circle / B -spline interpolation accuracy + / -0.5 pulse 4-way Universal opto-isolated OC gate output , maximum 500mA drive capability ( with free wheeling protection ) 4-way Universal opto-isolated inputs , compatible with 5V/12V/24V logic level The most remarkable features of RDC644XG Controller: the most remarkable features of RDC644XG Controller: 1 , Ethernet (10/100M) and USB2.0 transmission , the controller automatically query mode of communication ; 2 , true color TFT screen that can display true color graphics processing on the panel , and accurately informed of the coordinate position of the laser processing head on the panel ; 3 , the status bar to indicate the current frame size of the file , the network connection status, etc. ; 4 , can be stored in memory on the panel preview graphics files , its refresh rate, domestic manufacturers and no one can ; 5, the dynamic display processing tracks and coordinates ; 6 , the whole dynamic display graphics processing progress bar ; 7 , each layer can directly modify the processing parameters on the control panel ( such as: speed, power , etc. ) , while the layer parameters modified can automatically preserved for later use ( this feature can not be achieved other vendors . ) ; 8 , support for power outages continued carving , hours preview ( accurate to the millisecond , preview and actual working hours time spent exactly the same , other manufacturers can not achieve this functionality ). 9 , support for feeding, lifting , rotating sculpture, about the push plate and other functions. 10, RDC644XG Core Technology Development System is the latest generation of laser engraving / cutting control system , the control system has better hardware stability, better resistance to high pressure, anti-static properties of the interference . 11 , the controller uses better, more optimized motion control algorithm , its processing speed and efficiency before and the system can not match . Applications Laser cutting (double plus scrap automatic typesetting features, support progressive feeding) Laser Engraving Laser Welding We ship by DHL, UPS,TNT,Fedex or EMS. Usually will take 7 days to receive it.
