Reel-o-matic Mini Penthouse/mini-pent Wire Measuring/coiling Machine Puller

US $5,737.49

Phoenix, Arizona, United States
Jun 2nd

Open on mobile:
QR code

Reel-O-Matic Mini Penthouse/MINI-PENT Wire Pulling/Measuring/Coiling Machine/De-reeler with 1700 Material Measuring Meter Comes with what you see in the pictures. If you don't see it, you probably won't get it. Specifications are from Reel-O-Matic and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit has been tested to spin and variably. It is guaranteed to work. The Main Unit's Serial Number Tag Reads: Model Number: MINIPENT Serial Number: 2-8702-I12 Capacity: 100 lbs. The Facility Requirement's Tag Reads: Power Requirements: 120 VAC, 60 Hz, Single Phase, 15 A Largest Motor: 1 HP The Measuring Meter's Serial Number Tag Reads (this tag is really hard to read so may be off a bit): Model Number: 1700 RHPO Serial Number: 2408 Test Length: 500 Actual Length: 499.1 The Motor Gear's Information Reads: Input H.P.: 1.16 Output Torque: 875 lb.in. Ratio: 25 RJ Catalog Number: HF721R25KB5HP20 The Motor's Information Tag Reads: Catalog Number: 108022.00 Model Number: C4D17FK5K RPM: 1750 HP: 1 Voltage: 90 V Type: DF Amps: 10 Series Factor: 1.0 Duty: Continuous Max. Ambient Temperature: 40°C Frame: S56C Insulation Class: F3 Torque: 36 inch-lbs. F.F.: 1.34 Enclosure: TEFC Date Code: H12G Description: The "Mini-Penthouse" is ideally suited for pulling material from reel racks, reel roller platforms or a pay-out cart. Also, ideal for use with an extrusion line when equipped with a dancer or tension control. Standard Features: Variable Speed Control 1 HP SCR Drive System, 120 V, Single Phase, 0-70 RPM ROM 1700 Measurer 1/8" to 2" Diameter Capacity Feet & Inch Mechanical Counter Heavy Duty Mobile Frame with Floor Locks 2 Swivel Wheels for Maneuverability Operator Safety Foot Switch 5C-4 Collapsible Coiler 20" ID x 30" OD x 5" Wide 1700 Measuring System Capacity: 1/8" through 2" Diameter Overall Approx. Dimensions: 69.25" W x 54" H x 39.25" D $150.00 minimum for packaging, handling, and order processing. Shipping to be determined by destination. Prior to shipment I will need to know the following information (filled out on a form that I will send you) for International Customers or Packages/Freight being Forwarded internationally. International customers may also be subject to a freight forwarder form if applicable.: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? 06/02/21

“This unit has been tested to spin and variably. It is guaranteed to work.”

Model

MINIPENT

Brand

Reel-O-Matic

MPN

MINI-PENTHOUSE

UPC

Does not apply
