REFLECTOR 4pcs 6P14P / EL84 / 7189 / 6BQ5 PENTODE TUBES, NOS, US $16.00 – Picture 0
REFLECTOR 4pcs 6P14P / EL84 / 7189 / 6BQ5 PENTODE TUBES, NOS, US $16.00 – Picture 0

Reflector 4pcs 6p14p / El84 / 7189 / 6bq5 Pentode Tubes, Nos

US $16.00

  • Tbilisi, default, Georgia
  • Jan 29th
Open on mobile:
QR code
REFLECTOR  4pcs  6P14P / EL84 / 7189 / 6BQ5  PENTODE TUBES  NOS 6n14n, 6n14n-B, 6n14n-EB) General Pentode for output stages of low frequency amplifiers. Envelope: miniature, glass. Mass 20 g. Lead diagram General characteristics: Type 6P14P 6P14P-V 6P14P-EV Filament voltage, Volt 6.3 6.3 6.3 Anode voltage, Volt 250 250 250 2nd grid voltage, Volt 250 250 250 Resistance in cathode circuit, Ohm 120 120 120 Type 6P14P 6P14P-V 6P14P-EV Filament (heater) current, mA 760±60 760±60 760±60 Anode current, mA 48±8 48±8 48±8 2nd grid current, mA 5 5 5 Reverse 1st grid current, mkA ? 1 ? 1 ? 1 Dissipate cathode-heater current, mkA ? 25 ? 25 ? 25 Mutual conductance, mA/V 11.3 11.5 11.5 Output power (by RA=5.2Kohm), W 4.2 4.3 4.3 Non-linear distortion, % 8 8 8 Internal resistance, Kohm - - - Equivalent noise resistance, Ohm     300 Inter electrode capacitance, pF: input 11 11±2.5 11±2.5 output 7 8±2 8±2 transfer ? 0.2 0.75-0.4 0.75-0.4 Operation time, h 3000 1000 5000 Limited operating values: Type 6P14P 6P14P-V 6P14P-EV Filament voltage, V 5,7-7 5,7-7 5,7-7 Anode voltage, V 300-400 300-500 300-500 2nd grid voltage, V 300 300-500 300-500 Cathode - heater voltage, V 100 200 200 Cathode current, mA 65 65 65 Anode dissipation, W 14 14 14 2nd grid dissipation, W 2.2 2 2 Resistance in 1st grid circuit, MOhm 1 1 1 Operating environmental conditions : Type 6P14P 6P14P-V 6P14P-EV Acceleration of vibration loads, g 2.5 6 10 by frequencies, Hz 50 5-600 5-600 Acceleration of multiple impacts, g 35 150 150 Acceleration of single impact, g -- 300 300 Ambient temperature, °? -60 to +70 -60 to +70 -60 to +70 Relative humidity at up to 40°C, % 98 98 98 Plate-grid and plate curves of 6P14P Plate-grid and plate curves of 6P14P-EV
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand REFLECTOR
Country/Region of Manufacture Unknown
Model EL84
