Relay Protection & Electric Automation Components Setup Tester Analyzer Y5052

US $5,980.00

Lviv, Europe, Ukraine
Jan 29th

Open on mobile:
QR code

High precision Device Y5052 analog of Lutron, Advantest, Avtech, HP Agilent, NoiseCom, General Radio, Boonton, Anritsu, Fluke and general Electric, but has the same or better characteristics. This device can be used for wide measurement range. Is designed for simple relay protection and electric automation components setup and testing at install place in power plants, substations and industrial plants or laboratories. It consists of two blocks - K513, K514 Device Y5052 is designed for easy relay protection and electric automation components setup (relays, contactors, motor starters, etc.) in place of their installation in power plants, substations and industrial plants or laboratories. Device Y5052 consists of two blocks (K513 - adjustment block and K5I4 - load block) is electrically interconnected with a plug connection cable. Device Y5052 is designed for operation: Y5052 - in temperate climate, dry heated rooms at an ambient temperature from 10 ° to 35 ° C and relative humidity up to 80% (at 25 ° C), and can also be used when working outdoors in deletion of water falling on it splashes and droplets; Y5052 T4.1 - tropical version - in a dry or wet tropical climate in indoor air-conditioned at temperature from 1 to 40 ° C and relative humidity up to 80% at 25 ° C (GOST 15150-69). Condition: NEW (not used, an old stock). Tested and 100% workable. If necessary, we can provide calibration certificate from Government standardization institute (+145-265usd). Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Also we can provide other resistance, capacitance and inductance standards, decade box and other etalons. Please take a look on my other items! If you haven’t found the needed item in my listing, please contact me. I’ll try to help you. Technical characteristics of devices Complex measurement set Device Y5052: Device Y5052 provides: Receipt of controlled single-phase AC and rectified DC voltage; Tested devices temporal characteristics measurement. Device power supply - AC frequency 50 Hz ± 0.5 Hz, voltage 220 or 380 V, with capacity at least 6 kV • A Adjusting block K5I3 at nominal voltage supply (220 or 380 V) provides: at output terminals electrical quantities in accordance with table 1. Table 1 Voltage and current type Voltage load Acceptable duty cycle at indicated load conditions, min Regulation Output clamps Position Voltage, V Current, A 1.Alternating 380V 2? 30 sliding gear "=U" "OFF" 380V 5? 1 330V 10?* 0.5 2. Constant (rectified with smoothing) 240V 0.06? 30 "U?" 220V 0.6? 5 110V 1.0? 5 - 4.5? 1 3. The same 210V 1.0? 5 absent "Un?1" 200V 0.65? 1? 5 "Un?2" 4. Rectified (without smoothing) - 4.5? 5 smooth "Id" "off" * Current measurement is performed by external ammeter. Currents and voltages deviations are allowed from those given in table ± 15%; Performing both paragraphs 1 and 4 or 2 and 4 table 1. Device must be switched off for at least 45 minutes to cool down after each of modes listed in table 1; Sinusoidal shape of AC voltage at clamps "= U" at current 5 A, voltage 380 V and resistive load, with difference between coefficients of nonlinear distortion voltage at load ("= U") does not exceed 5%; Pulse coefficient voltage and current at clamps "= U" is in accordance with table 2. Table 2 Load range Pulse coefficient at load, %, at least Switch position "S12" (mkF) Voltage, V Current, A 240V 0.06? 2 "100" 220V 0.6? 3 "500" 110V 1.0? 3 "1000" " 4.5? 20 "1000" Voltage determination (current, operation, relay returns and other devices AC and DC), including current relays DC parallel and serial windings. Determination of unidirectional parallel windings and serial DC winding relays. Definition of response time (return) devices subjects (at closing, NC, and temporarily-closed contact) with built-in device Y5052 electric stopwatch PV-58SCH milli stopwatch or external (for example F209, F738, FIB, EMC-54). The alarm contact closure checked relays. Table 3 Nominal current, verifiable by device Y5052, A Measuring range of current, A Turn on duration load mode , min 30 At voltage, V 220 or 380 And resistance in the primary transformer load circuit, Ohm «0» I, ? U, V I, ? U, V 5? 25? 6.5? 120V 13? 117.0V 50? 13? 60V 26? 58.5V 100? 20? 38V 40? 38.0V 200? 40? 19V 80? 18.7V 1? 10? 2? 350V 4? 375V 10? 2? 350V 4? 375V Nominal current, verifiable by device Y5052, A Current measuring range, A Turn on duration load mode , min 3 At voltage, V 220 or 380 And resistance in the primary transformer load circuit, Ohm «20» «70» «200» I, ? U, V I, ? U, V I, ? U, V 5? 25? 20? 64V 11.1? 35.6V 4.75? 15.2V 50? 37.5? 30V 20.0? 16V 9? 7.2V 100? 73? 14.5V 34.5? 6.9V 14.5? 2.9V 200? 130? 6.5V 66? 3.3V 28? 1.4V 1? 10? 4.4? 100V 1.96? 49V 0.78? 19.5V 10? 3.5? 355V 2? 248V 1? 140V Nominal current, verifiable by device Y5052, A Maximum current range, A 0.5 At voltage, V 380 220 And resistance in the primary transformer load circuit, Ohm «0» I, ? U, V I, ? U, V 5? 25? 35? 112V 27.8? 89V 50? 67.5? 54V 55? 44V 100? 150? 30V 100? 20V 200? 240? 12V 196? 9.2V 1? 10? 10? 250V 10? 250V 10? 5? 500V 5? 440V Block K5I3 with block K514 at nominal voltage supply (380 or 220) provide: Smoothly - step regulation of single-phase AC. Parameters of load, depending on duration of set turn on, nominal voltage and transformer primary circuit load resistance are shown in table 3. Current and voltage deviation ± 25%; Simultaneous fulfillment conditions table 3 and p.3 table 1. At the same time may be reduced by current and voltage at load, compared with above 15%. Work in the intermittent mode (PKP), is characterized by time intervals shown in table 4. When performing PKP set provides currents and voltages specified in table 3 for duration turn on 0.5 min. Table 2 Cycles number 1 2 3 On time set, s 10 - 10 - 10 - 10 - 10 - 10 - 10 - 10 - 10 Duration of set disabled state, s - 30 - 30 - 120 - 30 - 30 - 120 - 30 - 30 - Device Y5052 should be switched off for at least 45 minutes to cool down after each, of modes listed in table 3, 4, 5. Sinusoidal shape of AC current in active load circuit at current 50 A, connected to clamps "1

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Y5052
MPN	Y5052
Model	Y5052
