Renishaw Tp20 Cmm Probe Kit One Medium Force Stylus Module With 90 Day Warranty

US $1,050.00

Minneapolis, Minnesota, United States
Sep 1st

Open on mobile:
QR code

Powered by Frooition Shop Categories OtherRenishaw ProductsRam Optical and OGPMasters and StandardsPrecision Measuring ToolsCMM and VMM Probing SystemsMachine Tool Probing SystemsCMM PartsVideo Measuring Machine PartsCoordinate Measuring MachinesVideo Measuring MachinesProfile Surface and Roundness Renishaw TP20 CMM Probe Kit One Medium Force Stylus Module with 90 Day Warranty Item Description Used in box Renishaw TP20 Touch Probe Kit with one Medium force stylus module with 90 Day Warranty. This probe has been tested and guaranteed to meet Renishaws original specification. Kit includes TP20 body, Medium force stylus module, manual, cleaning kit, spanner and styli tools in Renishaw foam lined box. If your application requires other than the Medium force stylus module please contact us for availability. About TP20 The TP20 is a compact 5-way, or 6-way, kinematic touch-trigger probe system. The two-piece design, comprising probe body and detachable stylus module(s), connected using a highly repeatable magnetic kinematic coupling. This provides the facility to change stylus configurations either manually or automatically without the need for requalification of the stylus tips, thereby giving significant time savings in inspection routines. Modules offering a range of trigger forces allow the probe performance to be best matched to the measurement task. A set of probe extensions is also available, as is a 6-way module. The stylus mounting thread accepts styli from the Renishaw M2 range. The TP20 system is easily retrofitted and is compatible with existing touch trigger probe interfaces, extensions and adaptors. System components The system components are: TP20 probe body TP20 probe module - seven variants allow optimisation to suit application MCR20 module changing rack - automatic operation MSR1 module storage rack - manual operation Suitable for interfacing with Renishaw's PI4-2, PI7-2 or PI200 TP20 specification Sense directions All modules except 6W 6W ±X, ±Y, +Z ±X, ±Y, ±Z Suitable interface PI4-2, PI7-2, PI200, UCC Pre-travel variation LF SF / EM1 / EM2 MF EF 6W ±0.60 µm (± 0.000023 in) ±0.80 µm (± 0.000032 in) ±1.00 µm (± 0.000039 in) ±2.00 µm (± 0.000079 in) ±1.50 µm (±0.000058 in) Unidirectional repeatability LF / SF / EM1 / EM2 MF EF 6W ±0.35 µm (± 0.000014 in) ±0.50 µm (± 0.000020 in) ±0.65 µm (± 0.000026 in) ±0.80 µm (± 0.000032 in) Repeatability of stylus changing MCR20 Manual ±0.50 µm (± 0.000020 in) ±1.00µm (± 0.000040 in) Stylus range M2 Mounting method M8 thread Probe modules A range of seven, application specific, probe modules is available and are identified by coloured caps. Module Application Trigger forces Stylus lengths SF - Standard force Suited to the majority of applications XY: 0.08 N Z: 0.75 N Stylus: 10 mm 10 - 50 mm GF LF - Low force Low trigger forces applications - e.g. rubber seals XY: 0.055 N Z: 0.65 N Stylus: 10 mm 10 - 30 mm MF - Medium force Where a higher trigger force than standard is required XY: 0.1 N Z: 1.9 N Stylus: 25 mm 10 - 60 mm EF - Extended force Large stylus assemblies or where vibration causes spurious 'air' triggers XY: 0.1 N Z: 3.2N Stylus: 10 mm 10 - 60 mm 6W - 6-way Measurement in the -Z direction - e.g. undercuts XY: 0.14 N Z: 1.6N Stylus: 10 mm 10 - 50 mm EM1 STD - 50 mm extension Majority of applications requiring a 50 mm extension XY: 0.08 N Z: 0.75 N Stylus: 10 mm 10 - 50 mm EM2 STD - 75 mm extension Majority of applications requiring a 75 mm extension XY: 0.08 N Z: 0.75 N Stylus: 10 mm 10 - 50 mm This is by far the best price you will find for a Renishaw TP20 probe kit and one Medium force stylus module with 90 Day Warranty Why pay retail when you can purchase with warranty from Metrology parts. Purchase with confidence from a Paypal verified retailer with 90 Day Warranty. If what you order is not what you receive you will be refunded the full purchase price for this sale. Metrology Parts would like the opportunity to earn your business for this sale and all of your future Renishaw product needs. If you have any questions feel free to contact us. With 32 plus years of experience with Renishaw products we can help with all of your application needs as well as your after sales support. About Us About Us Payment Shipping Terms Returns About Us Payment Payment Shipping Shipping Terms Terms Returns Returns Metrology Parts always strives for 100% customer satisfaction. If for any reason, you are unhappy with your purchase from us we would like to hear from you on how we could have improved your shopping experience. We understand that sometimes mistakes can be made in orders or sometimes there is buyer?s remorse. We have a 60 day return policy on all items. Please do be advised that all items need to be returned in original packaging with all manuals, certificates and unopened tool kits. If items have been installed and show installation marks we can only offer a partial refund on items we cannot resell as new or return to the factory. If you are having issues with equipment in your facility and are in need of help troubleshooting prior to purchase, we offer free technical support to make sure the correct parts get ordered. Free technical support is also offered on all items purchased to make sure your installation goes smoothly. Should you need to return items purchased from Metrology Parts please contact us for an RMA, address we would like the item shipped and instructions on shipping your return to us safely. On behalf of Metrology Parts, we would like to thank you in advance for the opportunity to earn your business. Helpful Links Add to Favorite Sellers Sign up to Newsletter View Feedback Contact Seller Visit seller's eBay Shop About Seller Page More Items! View more great items Renishaw TP200 CMM Probe Kit Three SF Modules New in Box with 1 Year Warranty $3,700.00 Renishaw TP20 Non-Inhibit CMM Probe Kit 1 New 2 Modules with 1 Year Warranty $2,150.00 Renishaw SP25M SM25-3 CMM Scanning Probe Kit 3 Display Model w 6 Month Warranty $4,950.00 Renishaw CMM PH10MQ PLUS PHC10-3 Controller All New in Boxes 2 Year Warranty $11,500.00 Powered by Frooition Frooition Frooition | No-js Template | eBay design, eBay store design, eBay shop design, eBay template design, eBay listing design (ver:froo_no_js)

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	MPN	A-1371-0293
Model	TP20
Country/Region of Manufacture	United Kingdom
Country of Manufacture	United Kingdom
Brand	Renishaw
