Replace Apc220 Uart Wireless Serial Data Module With Usb Adapter Kit For Arduino

US $19.99

Guangzhou, China
Jan 29th

Open on mobile:
QR code

Below item is powered by Canton-electronics Ltd . Product Name: replace APC220 UART Wireless serial Data Module with USB Adapter Kit for Arduino Module No.: TB389 Packing list: 2 pcs 2.4G RS232(TTL Lever) Wireless Transceiver Module; 1 pcs USB to TTL 232(Ch340 IC) 1 pcs 5pins female to female dupont wire; 2.4G UART + USB TO TTL: 2.4G Wireless communication between Arduino and PC Wireless data transmission(Also application with other 3.3V/5V level MCU ,for example: FPGA CPLD STM32 C8051 PIC AVR MSP430 ARM) NOTE : Packing list Does not include Arduino UNO ARDUINO IDE Serial Port Transceiver: Copy the following code: //----------------------------------------------------------------------// // Pin 13 has an LED connected on most Arduino boards. int led = 13; String comdata = ""; void setup() { // initialize the digital pin as an output. pinMode(led, OUTPUT); Serial.begin(9600); Serial.println("Hello, I am Arduino!"); } //Serial data transceiver void loop() { while (Serial.available() > 0) { digitalWrite(led, HIGH); // turn the LED on (HIGH is the voltage level) comdata += char(Serial.read()); delay(2); } if (comdata.length() > 0) { Serial.println(comdata); comdata = ""; } digitalWrite(led, LOW); // turn the LED off by making the voltage LOW } //----------------------------------------------------------------------// Overview: TB387 is based on 2.4GHz frequency band wireless transparent data-transmission module. Module supports most basic AT commands: baud rate, ID number, frequency settings and inquiries; factory settings; version information. When the module is in AT module, users can use serial-port to issue AT commands to set the module's parameters. When the module is in transparent data transfer mode, the user transmit data, frame number data module, add packaged rowcount, and then automatically transmit , at reliable range, the module will automatically re-transmit data to ensure successful transmission. For more details : Please contact seller on ebay message ; Performance Parameter: Working voltage: 3.3V/5V; RS232 Interface ( 3.3V/5V TTL level) Frequency range: 2402~2482MHz Transmit power: 20dBm(100mw); Receiver sensitivity: -87dBm; Operating temperature: -40~+85 ° c; 10 kinds can set the baud rate: 2400,4800,9600(Default),14400,19200,38400,57600,115200,12800,25600 AT mode configured baud rate fix is: 9600; Open ground Transmission distance(5V Power) : 400 meter when transmitting, current up to 120mA; receiveing current is 30mA , please use smaller ripple power supply Pinout : 1, VDD:3.3V / 5V power supply ; 2, GND: Power Ground; 3, TXD: serial port output, Arduino or USB to TTL232 RXD; 4, RXD: serial port input, Arduino or USB to TTL232 TXD; 5, CMD: Enter PIN AT mode, active low level; USB to TTL 232 CH340 Driver : http://www.winchiphead.com/download/CH341/CH341SER.ZIP Typical applications: Arduino Wireless data transmission Replace APC220 Wireless serial Data Module Home Automation 2402-2482MHz ISM/SRD band systems Consumer electronics Access control, Attendance, Logistics Smart Furniture Robert Wireless sensor Remote control, remote measurement system; Wireless meter; Access control ; Identification system; Data collection; IT household appliance; Intelligence household appliance ; Baby monitoring system; ★Introduction for Shenzhen Canton-electronics Trading Co.,Ltd : We specialize in RF Wireless Radio Transmitting Units and Receiving Units, the product include transmitters with case, receivers with relay(s), transmittng modules and receiving modules, are widely applied in RC toy, remote sensing, telemetry, fireworks, industrial control, home&garden application. ★Shipping: Normally shipping is by Airmail from China Post Air Mail or Hong Kong Post Air Mail ,15-60 days shipping time based on different country . Express is available, shipping time is 2-7 days all over the world, and telephone number is needed. Please contact us first for extra payment . ★Benefits The Best Prices. By working with Canton-electronics Ltd, you can take advantage of the internet business, cut off the wholesalers cost and other costs, and import your products directly from the manufacturer at incredible prices. Prompt Delivery. Most units are in stock all the time, standard units will be completed within 1-3 days if they are sold out, it is great help for you if your project must be completed before deadline. Prompt Service. Mails will be replied within 24 hours We work 6 days a week. ★Return Policy All mails will be replied to within 24 hours except on weekend and holidays. Every item is manufactured under Strict Quality-Assurance Guidelines. If you are dissatisfied for any reason, please return the product to us, and we'll refund your money(not including shipping fees). Please ensure that return items are not used. Return items must be Posted within 7 days of receipt. Please inform us via email before posting your return package. ★PAYMENT •We accept PayPal only. •We only ship item to your PayPal verified address. •Payment must be received within 3 Days from the date of purchase. •Please leave note in PayPal when making the payment if you have any special request (colors/size). ★Import tax : We will dispatch the item as SAMPLE or GIFT, label the total amount on the custom declare invoice . Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. Please check with your country’s customs office to determine what these additional costs will be prior to buying. Engineered for professional eBay sellers!
