Payment Shipping Terms Return policy Feedback Contact us Rex-c100 SSR Digital LED Temperature Control Controller Thermostat ++Description++ Automatic correction fuction Large LED screen display Heating/Cooling control Digital communication Temperature alarm Product Name: RKC temperature controller Model: REX-C100 Color: Black Range :0-400 Celsius Input: K Power :100-240V AC, 50/60HZ Size: 105 x 55 x 47mm Main structure and function * Self-correction function * Large screen LED display * Heating / cooling control * Digital Communication * Temperature alarm Heater break alarm Control loop break alarm Product Description: Input a) thermocouple (TC): K, J, E, T, R, S, B, U, L, N, PL2, W5Re/w26Re b) Thermal resistance (RTD): Pt100 JPT100 c) DC input: DC0 ~ 5V, DC1 ~ 5V, DC0 ~ 20mA, DC4 ~ 20mA Requires connecting250W resistor between the terminals Input Display Accuracy: (0.3% +1 bit of the setting value) Input range: Refer to Input Range Table Sampling period: 0.5sec Process value bias -1999 ~ 9999 Celsius [° F] or -199.9 ~ 999.9 Celsius [° F] (temperature input) ±full scale (voltage / current input) Setting range a) the set value (SV): identical with temperature value range b) heating side proportional band (P): 1 or 0.1 scale range (temperature input) x 0.1% to 100.0% scale range (voltage input) c) Cooling side proportional band (Pc): 1% ~ 1000% heated side proportions d) Integral time (I) :1-3600sec x 2 e) Derivative time (D) :1-3600sec x 3 f) Effective limited scope of the integral action (ARW): 1% -100% proportional band x 4 g) heating side proportional cycle 1-100sec x 5 h) Cooling side proportional cycle 1-100sec x 6 i) Senseless band: -10-10 or-10.0-+10.0 Celsius [° F] (temperature input) -10.0 % - +10.0% of range (voltage / current input) x 7 * 1 If the proportional band is set to 0 Celsius [° F], ON-OFF action * 2 If the integration time is set to 0sec, PD action * 3 If the derivative time is set to 0sec, PI action * 4 If the effective limited scope of the integral action is set to 0%, OFF * 5 No need to set the current output circle * 6 If the senseless band is set to a negative one, overlap Control action PID control (ON-OFF, P, PI, PD control) a) automatic calculation function (AT) (1) self-adjusting mode: limited cycle method (2) AT cycle: 1.5 b) self-correction setting setting is changed, then the self-correction is established * Excluding heating / cooling PID control action Control Output a) relay contact output: 250VAC 3A (with load) 1a connection * Electrical: more than 300,000 times, the rated load b) Voltage pulse output :0-12V DC (Load resistance: More than 600 ?) c) Current output: 4-20mA DC (load resistance: less than 600 ?) d) Thyristor control tube drive triggerring output: zero measurement, medium capacity drives e) Thyristor control tube output: rated 0.5A (ambient temperature is below 40 Celsius) Temperature alarm Alarm point: Dual Alarm (set separately) Alarm types: Deviation alarm (upper limit, lower limit, upper and lower limit, within the range) Process value input alarm (upper limit, lower limit) Setting value alarm (upper limit, lower limit) * You can select a standby function (except the alarm setting value) Control loop break alarm (LBA) LBA set time: 0.1-200.0 min * Can not be set to 0.0 min LBA no sense with: 0-9999 Celsius [° F] (temperature input) 0 - range (voltage / current input) * If set to 0, LBA does not operate. Heater break alarm (HBA) Input: current detection output (RKC designated Model CTL-6-PN, CTL-12-S 56-10L-N) Suitable scope: CTL-6-PN 0-30A CTL-12-S56-10L-N: 0-100A Alarm Output Relay contact output, 250V AC 1A (with load) 1a connection * Off more than 50,000 times. * Control loop break alarm output should be selected in one of the ALM1 or ALM2. * When the control loop break alarm is selected, another alarm can't be set to LBA. Communication functions (SCI) Protocol: ANSI X3.28 (1976) 2.5 A4 Communication Method: 2-wire half-duplex multi-station connection Synchronization method: start / stop synchronization Communication speed: 2400,4800,9600,19200 BPS Digital start: 1 Data Digital: 7 or 8 Parity checking: with or without, such as "yes" when: Odd Number or Even Number Stop bit: 1 or 2 The maximum number of connection points: 32 points (address setting 0-99) Other Power impact: no impact off the spreadsheet for 20ms or less Off for more than 20ms, return to the initial state Power data protection: do not disappear and support data Ambient temperature: 0-50 Celsius [32-122 ° F] Ambient humidity: 45-85% RH Installation: embedded disk installation ++Package included++ 1 x Temperature controller 1 x English user manual Packed in carton Payment Shipping Terms Return policy Feedback and Detailed Seller Ratings Contact us We only accept payment through Paypal. Please make sure you have a valid PayPal account prior bidding. Please pay for your item within 5 days of the auction end time. All items will be shipped to buyer's ebay address. Before you pay, please make sure your address in ebay matches the address you would like us to ship to. All items will be shipped within 48 hours upon receipt of payment. In most cases, international shipping takes around 7-14 business days. We try our best to provide you with the most reliable, affordable way of shipping. But sometimes international delivery is highly dependent on the local customs and post service. If you do not receive your item on time, please contact us immediately for further assistance. We take responsibility for any damages or losses incurred in the shipping process. Listings with shipping and handling charge: the charge covers mailing, packing, warehouse and distribution costs, not only postage. Please Note: Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying. If any item is defective upon receipt, please contact us for the return address, returns are accepted within 14 days after the buyer receives the item. Returned item has to be in its original condition. Buyer is responsible for return shipping costs. After receiving the return we will make a replacement depending on our available stock, if not available, a refund will be issued. Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us positive feedback and rate the details of the transaction (Detailed Seller Ratings) with a "PERFECT 5 STARS". When you rate the shipping time section please take international transit into consideration.Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and have a pleasant shopping experience with us. Please email us before leaving any 1 or 2 ratings, negative feedback or open any dispute. We understand the concerns and frustrations that occasionally occur, and appreciate the opportunity to assist you in resolving any problem associated with your purchases. We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply to your emails as soon as possible, however, due to high volume of daily incoming emails and time zone difference, we may not be able to reply your emails immediately. Please allow 24 business hours for us to respond. About item:For the functional products in our shop (such as: Chargers, Data cables), we make sure that the functions are the same as description, but the actual color and shape may looks a little different from pictures because of the technical improvement and manufacturing variance. Please be advised before you bid.
