Rf Field-probes Sniffer Dc - 6ghz With Emc Preamplifier

US $3,998.00

Auw, Germany
Feb 15th

Open on mobile:
QR code

Near Field Probe Set PBS2 DC to 6GHz RF Field-Probes to measure E & H fields with EMC Preamplifier Details see manufacturers website at aaronia.com Only US$ 3998 incl. worldwide EXPRESS shipping and 10 years warranty! RF Field Probe Set compatible with any Spectrum Analyzer or Measurement Receiver Design: Passive H & E field probes Frequency range: DC (1Hz) to 6GHz Nominal impedance: 50 Ohm Preamplifier: UBBV2 (40dB, DC to 8GHz) Gain: Diff. Depending on probes (see data sheets) Antenna factor: Depending on probes (see data sheets) RF connection: SMB (m) or SMA (see optional adapter) Tripod connection: 1/4" Warranty: 10 years Highlights: 5 different RF probes to measure H and E fields offer optimum sensitivity and spatial resolution at different frequencies Passive or active mode by removing/adding included preamplifier Preamplifier with integrated LiPo battery (up to 3,5h run time) Covered with insulating layer for safe measurements Very handy design incl. rubber coated grip Very small size. Perfect for exact locating of interference sources. Offers access to tight spaces Integrated electrostatic shield eliminates common-mode pickup Can be driven by a signal source to generate fields for electromagnetic susceptibility testing Gain rises very linear with frequency which offers high accuracy Preamplifier offers integrated calibration data on EEprom (readout via integrated USB interface) Typical standard calibration data and Excel sheet for dBm to V/m and A/m conversion (on CD) Extra wide frequency range up to 6GHz Suitable for field-strength and EMC measurements due to high precision Including tripod connector for perfect adjustment and reproducibility Included in delivery: 1 x 50mm magnetic (H) field probe PBS-H4 1 x 25mm magnetic (H) field probe PBS-H3 1 x 12mm magnetic (H) field probe PBS-H2 1 x 6mm magnetic (H) field probe PBS-H1 1 x stub electric (E) field probe PBS-E1 UBBV2 EMC broad band RF Preamplifier 2 mounting brackets for SPECTRAN LiPo-Battery (integrated in UBBV2) Battery charger and power supply for UBBV2 broad band PreAmp incl. international adapter set SMA tool Cleaning brush Aluminum carrying case with foam protection Pistol grip with mini tripod function SMB to SMA cable (1m) Typical calibration data and Excel sheet for dBm (power) to V/m (electric field), A/m, T and G (magnetic field) conversion (on CD) Aaronia AG, Gewerbegebiet Aaronia AG, DE-54597 Euscheid, Germany Tel. ++49(0)6556-93033, Fax ++49(0)6556-93034 Email:mail@aaronia.de URL:www.aaronia.com
