RF microwave dual junction isolator 890 MHz CF/ 320 MHz BW/ 100 Watt / data, US $194.99 – Picture 0
RF microwave dual junction isolator 890 MHz CF/ 320 MHz BW/ 100 Watt / data, US $194.99 – Picture 0

Rf Microwave Dual Junction Isolator 890 Mhz Cf/ 320 Mhz Bw/ 100 Watt / Data

US $194.99

  • Sunnyvale, California, United States
  • Jun 9th
Open on mobile:
QR code
All items in Telenochek RF store are categorized with extensive detailed categories to simplify searching through the items. Be sure to take advantage of the categories! For sale is: RF, microwave dual junction isolator in good working condition, tested with data. Please see pictures and data table. **Every individual item is tested prior to shipment** Common uses for isolators: Isolators are used for isolating circuits from imperfect 50 ohm impedance matches. Protection of PA (power amplifier) from VSWR effects at antenna / duplexer interface. Protection of frequency sources (PLL VCO, DRO etc...) from disturbances at the RF port / VCO frequency pulling. Inter-stage matching isolation such as isolation of PA driver from PA input match. Inter-stage matching isolation where filters and amplifiers are involved. Type Isolator dual junction Manufacturer Ditom Seller SKU TMRF_3L1 Port 1 N(f) Port 2 N(m) Insertion Loss (dB) -0.80 Isolation (dB) -30 to -50 Center Frequency (MHz) 890 1dB Pass Bandwidth (MHz) 320 Low Frequency of Operation(MHz) 730 High Frequency of Operation (MHz) 1050 Forward power handling ( Watt CW) 100 Watt CW For high power testing - we can provide s-parameter sweeps before and after applying high RF power (currently up to 200 Watt RF CW depending on frequency). Please inquire if interested in high power. Reverse power handling (Watt) 2 Watt CW (limited due to integrated 50 ohm termination) Shipping: We always pack with care to ensure your item arrives safely in original condition. To lower your shipping costs, we can combine shipping for items purchased within several days. International shipping: We ship internationally. An international shipping estimate calculated by eBay is only an estimate. International customers please contact the seller for shipping price before bidding or purchasing. Buyer is responsible for all extra fees associated with international shipping, such as import and customs duties. Return policy: We work with our customers to resolve any issues they might have. Majority of our items have been professionally tested. Any known problems with components, equipment etc... will be noted in the item description. Do you see an error in the listing? We try our best to provide accurate information and technical measurements. However, sometimes errors happen in the technical descriptions, pictures or data. Please let us know if you notice any discrepancies. Thanks! Thank you for your interest! Questions are invited! Please check out our store for similar items Additional search keywords: RF magnetics, RF isolator, RF, microwave, MHz, GHz, broadband , wideband, megahertz, gigahertz revision: 1.6 inventory: PWR1_cat Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
