Rf Microwave Lte C/a Cellular Band Pass Filter 1920-1980 Mhz Power 10 Watt /data

US $460

Sunnyvale, California, United States
Jun 17th

Open on mobile:
QR code

Increase traffic to your listing with Auctiva's FREE Scrolling Gallery. All items in Telenochek RF store are categorized with extensive detailed categories to simplify searching through the items. Be sure to take advantage of the categories! For sale is: RF, microwave, IF band pass filter in good working condition, tested with data. Please see pictures and data table. This filter came out of an LTE basestation test rack, used to test basestation performance. This is a 1920-1980 MHz BPF, covers FDD1 UL, does not cover PCS1900 (1930-1990 MHz) Please ask us to re-measure the noise floor (higher power VNA, lower resolution bandwidth, slower sweep time) if your requirements demand high absolute rejection (e.g. >100dB). The ~70dBc is a known limitation of our current test setup. Good for carrier aggregation. **Every individual item is tested prior to shipment** The filter is fixed and cannot be retuned to a different center frequency. Type BPF Manufacturer M-City Seller SKU TMRF_5G13 / TMRF_5G24 Port 1 SMA(f) Port 2 SMA(f) Insertion Loss (dB) -1.50 typical (-2dB max) Center Frequency (MHz) 1950 1dB Pass Bandwidth (MHz) 60 1dB Pass Low (MHz) 1920 1dB Pass High (MHz) 1980 Power handling ( Watt CW) 10 Watt CW For high power testing - we can provide s-parameter sweeps before and after applying high RF power (currently up to 200 Watt RF CW depending on frequency). Please inquire if interested in high power. Shipping: We always pack with care to ensure your item arrives safely in original condition. To lower your shipping costs, we can combine shipping for items purchased within several days. International shipping: We ship internationally. An international shipping estimate calculated by eBay is only an estimate. International customers please contact the seller for shipping price before bidding or purchasing. Buyer is responsible for all extra fees associated with international shipping, such as import and customs duties. Return policy: We work with our customers to resolve any issues they might have. Majority of our items have been professionally tested. Any known problems with components, equipment etc... will be noted in the item description. Do you see an error in the listing? We try our best to provide accurate information and technical measurements. However, sometimes errors happen in the technical descriptions, pictures or data. Please let us know if you notice any discrepancies. Thanks! Thank you for your interest! Questions are invited! Please check out our store for similar items Additional search keywords: band pass filter, BPF , bandpass filter, RF, microwave, MHz, GHz, broadband , wideband, megahertz, gigahertz E-UTRA, E-UTRAN, UTRA, UTRAN, BTS, eNodeB, basestation, emulator, BSS, LTE , UMTS, WCDMA, CDMA, CDMA-2000, AT&T, Sprint, Verizon, Vodafone, GCF, PTCRB, UE, Downlink, Uplink, cellular, coexistence, co-existence, rejection, collocation, co-location, ARFCN, EARFCN, UARFCN, FDD, TDD, OFDM, OFDMA, EVDO, HSPA, HSUPA, HSDPA, SCDMA, GPRS, multislot class, 1xRTT, AWS, isolation, WiFi coexistence, carrier aggregation, C/A revision: 1.5 inventory: PWR1_cat Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
