Rf Microwave Lte Gsm Cellullar Band 5 Notch Filter 869 - 894 Mhz / Power 20 Watt

US $230

Sunnyvale, California, United States
Jun 15th

Open on mobile:
QR code

Present your best items with Auctiva's FREE Scrolling Gallery. All items in Telenochek RF store are categorized with extensive detailed categories to simplify searching through the items. Be sure to take advantage of the categories! For sale is: RF, microwave, IF band reject / notch / band stop filter in good working condition, tested with data. Please see pictures and data table. This filter came out of an LTE basestation test rack, used to test basestation performance. It has 50dBc-60dBc rejection of 869-894 cellular downlink, which is LTE Band 5, or GSM / GPRS 850 and UTMS 850. Perfect for rejecting 850 Band 6 Japan as well, since it is a subset of Band 5. Unfortunately it does not quite pass the full 902-928 MHz unlicensed, as it starts passing around 906 MHz. Can handle 20Watt of basestation power. The filter is fixed and cannot be retuned to a different center frequency. **Every individual item is tested prior to shipment** Type Notch Manufacturer Microwave Circuits AMTI Seller SKU TMRF_5G3 Port 1 SMA(f) Port 2 SMA(f) Stop Band Performance: -50dB Notch Frequency Range (MHz) 869 - 894 MHz Notch Center Frequency (MHz) 881.5 -10dB Notch Bandwidth (MHz) 35 -10dB Notch Frequency Low (MHz) 864.0 -10dB Notch Frequency High (MHz) 899.0 Maximum Notch Depth (dB) 60 dBc Passband Performance: Full -3dB Passband Excluding Notch Frequencies (MHz) DC - 2300 MHz Insertion Loss in Passband (dB) -0.40 Power handling ( Watt CW) 20 Watt CW For high power testing - we can provide s-parameter sweeps before and after applying high RF power (currently up to 200 Watt RF CW depending on frequency). Please inquire if interested in high power. Shipping: We always pack with care to ensure your item arrives safely in original condition. To lower your shipping costs, we can combine shipping for items purchased within several days. International shipping: We ship internationally. An international shipping estimate calculated by eBay is only an estimate. International customers please contact the seller for shipping price before bidding or purchasing. Buyer is responsible for all extra fees associated with international shipping, such as import and customs duties. Return policy: We work with our customers to resolve any issues they might have. Majority of our items have been professionally tested. Any known problems with components, equipment etc... will be noted in the item description. Do you see an error in the listing? We try our best to provide accurate information and technical measurements. However, sometimes errors happen in the technical descriptions, pictures or data. Please let us know if you notice any discrepancies. Thanks! Thank you for your interest! Questions are invited! Please check out our store for similar items Additional search keywords: band reject filter, notch filter, bandreject, bandstop, band-stop, band stop, RF, microwave, MHz, GHz, broadband , wideband, megahertz, gigahertz, E-UTRA, E-UTRAN, UTRA, UTRAN, BTS, eNodeB, basestation, emulator, BSS, LTE , UMTS, WCDMA, CDMA, CDMA-2000, AT&T, Sprint, Verizon, Vodafone, GCF, PTCRB, UE, Downlink, Uplink, cellular, coexistence, co-existence, rejection, collocation, co-location, ARFCN, EARFCN, UARFCN, FDD, TDD, OFDM, OFDMA, EVDO, HSPA, HSUPA, HSDPA, SCDMA, GPRS, multislot class, 1xRTT, AWS, isolation, WiFi coexistence, carrier aggregation, C/A revision: 1.5 inventory: PWR2_cat Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
