Rg 59 20 awg Silver plated copper, foil + 80% tinned copper braid. Halogen Free., US $400.00 – Picture 0
Rg 59 20 awg Silver plated copper, foil + 80% tinned copper braid. Halogen Free., US $400.00 – Picture 0

Rg 59 20 Awg Silver Plated Copper, Foil + 80% Tinned Copper Braid. Halogen Free.

US $400.00

  • New York, New York, United States
  • Mar 13th
Open on mobile:
QR code
You are bidding on a 1000' reel of RG 59 designed to carry DS-3 and DS-4 between devices such as multiplexers, cross-connects and transmission equipment.  The center conductor is 20 awg of Silver plated copper for better attenuation performance. This cable has a foil shield + 80% tinned copper braid shield. This cable is also Halogen Free.  It has a Gray jacket. Manufactured in the US by Commscope.  DS-3/4 Interconnect and Cross Connect 75 Ohm Coaxial Cable Commscope 734S1H CMR Center conductor:  20 AWG Silver-Plated Copper Dielectric:  Foamed Polyethylene (FPE) Diameter over Dielectric: 0.150" Nom. Shield:  Foil: Aluminum/Poly Tape Braid: 34 AWG Tinned copper 80% coverage Diameter over Braid: 0.184" Jacket: Gray Non-Halogen Flame Resistant Polyethylene Diameter over jacket: 0.236" +/- 0.002" Min. Avg. Jkt. Thickness: 0.023" Min. Spot: 0.019" Electrical Properties: Sparker Test:  2500 VAC Dielectric Strength: Conductor to Shield: 5 Sec. @ 3500 VDC; Shield to Shield: 1200 VDC Capacitance: 17.0 pF/ft. Nom. Impedance: 75.0 +/- 3.0 Ohms Velocity of Propagation: 80% Nom. DCR: Conductor: 11.0 Ohms/1000 ft. @ 20 degrees C max. SRL: 30 dB Min. (15-90 MHz) 100% Swept Tested Mechanical Properties: Minimum Bend Test:  Loaded: 20 Times Cable OD;  Unloaded 10 Times Cable OD Jacket Temp. Rating: 75 degrees C  Please note that sales tax will be added to the following states: AZ, AR, CA, CO, CT, FL, GA, ME, MD, MN, NE, NV, NJ, NY, OH, PA, SD, TX
