Ridgid 325' Color Reel (14058) Navitrack Scout Locator (19238) Cs10 (39338)

US $2100

Wentzville, Missouri, United States
Jun 21st

Open on mobile:
QR code

Ridgid 325' Color Reel (14058) Navitrack Scout Locator (19238) CS10 (39338) Ridgid 325' Color Reel (14058) RIDGID SeeSnake video inspection systems offer unmatched reliability and performance in a ruggedized package. Each system offers: 100% hardened stainless steel camera head spring assembly for optimum durability Rugged, high-intensity lights for exceptional viewing and long life Flexible transmitters make locating easy and are compatible with RIDGID locators Can be used with any SeeSnake monitor or recorder Features 2" to 12" (50 - 300 mm) Lines up to 325' (99 m) Wide pipe diameter capacity range makes this system ideal for a wide range of inspection needs Specifications Line Capacity 2" - 12" (5-30cm) Maximum Run 325' (99m) Sonde 512 Hz Weight 53 lbs / 19.5 kg Reel Frame Diameter 32" / 81 cm Camera Diameter 1.365" / 35 mm Camera Length 1.68" / 42 mm Push Cable Diameter .44" / 11 mm Operating Temperature 32 F to 104 F Waterproof Depth 330' / 100 m Video Resolution 768(H) x 494(V) Navitrack Scout Locator (19238) The NaviTrack Scout Locator is designed to solve the most demanding remote transmitter (sonde) locates using multi-directional locating technology. Easier Locates The NaviTrack Scout multi-directional antenna technology sees the entire signal all of the time. Simply maximize the signal strength and you have found the target. No nulls or false peaks to complicate the locate. Accuracy This locator verifies the locate position using a micro-mapping display to mark distinctive poles in front of and behind the target, insuring an accurate locate. Automatic Depth Depth is automatically calculated and displayed when over the target. Weight 3 lbs (1,4 kg) Power Source 4 C-Cell batteries Battery Life Approximately 24 hours Specifications Weight 3 lbs (1,4 kg) Power Source 4 C-Cell batteries Battery Life Approximately 24 hours Standard Frequencies Sonde 512 Hz, 640 Hz and 33 kHz Line Trace 128 Hz, 1 kHz, 8 kHz and 33 kHz Passive AC Line Trace 60 Hz, 50 Hz Ridgid CS10 Digital Recording Monitor (39338) The CS10 Monitor combines RIDGID® durability with the easiest to use digital recording monitor in the industry. One touch recording allows you to record snapshots and video directly to a USB stick then hand it directly to your customer. Features USB Stick - recording lets you record digitally into a format that your customer can read on their computer 12.1" Daylight Readable Display - allows you to easily monitor and record inspections in bright outdoor environments Integrated Line Tracing - allows tracing the reel push cable with a RIDGID locator (requires a RIDGID transmitter) Multi Mode Recording - lets you take snapshots, record full frame video, and record in a lean video format called Auto-log (small files) Software Integrations - with SeeSnake HQ™ allow you to deliver your inspections in a wide array of formats from online to DVD Specifications Weight 13 lbs (5,9 kg) Length 14.3" (36,3 cm) Width 11.9" (30,2 cm) Height 12.4" (31,5 cm) Display 12.1" Daylight Readable LCD Resolution 640 x 480 Power Source 1 or 2 RIDGID 18V Advanced Lithium 2 Battery or AC Plug Audio Integrated Microphone and Speaker Video AVI 20FPS - 720 x 480 Image JPG - 720 x 480 Transfer USB stick Software Includes SeeSnake HQ Software
