Ridgid 325' Color Reel (14058) Sr-24 Locator (44473) "r-style" Iphone Monitor

US $1100

  • Wentzville, Missouri, United States
  • Jun 25th
Ridgid 325' Color Reel (14058) Seektech SR-20 Locator (21893) "R-Style" Iphone Recording Monitor Ridgid 325' Color Reel (14058) RIDGID SeeSnake video inspection systems offer unmatched reliability and performance in a ruggedized package. Each system offers: 100% hardened stainless steel camera head spring assembly for optimum durability Rugged, high-intensity lights for exceptional viewing and long life Flexible transmitters make locating easy and are compatible with RIDGID locators Can be used with any SeeSnake monitor or recorder Features 2" to 12" (50 - 300 mm) Lines up to 325' (99 m) Wide pipe diameter capacity range makes this system ideal for a wide range of inspection needs Specifications Line Capacity 2" - 12" (5-30cm) Maximum Run 325' (99m) Sonde 512 Hz Weight 53 lbs / 19.5 kg Reel Frame Diameter 32" / 81 cm Camera Diameter 1.365" / 35 mm Camera Length 1.68" / 42 mm Push Cable Diameter .44" / 11 mm Operating Temperature 32 F to 104 F Waterproof Depth 330' / 100 m Video Resolution 768(H) x 494(V) Seektech SR-24 Locator with Bluetooth & GPS (44473) The SR-24 is a precision utility locating instrument with GPS and Bluetooth® technology for easy integration with external data capture devices. The SR-24’s omnidirectional antennas capture the complete signal field, making it easy to acquire the signal and trace its path. The receiver displays the utility's position and direction on the display, providing an intuitive locating experience. For added confidence, audio and visual warnings notify the operator if the shape of the signal field is being distorted so that appropriate action can be taken to avoid mismarking the utility’s position. Features Large display - shows the utility’s estimated position, direction, and depth Omnidirectional antennas - capture the complete signal field for greater speed and accuracy Built-In GPS - track location coordinates for mapping and GIS applications Bluetooth® technology - stream data to smartphones, tablets, or high-precision GPS instruments Smartphone/Tablet App - map multiple tracks and waypoints and export to GIS software Can trace any frequency from 10 Hz to 35,000 Hz Specifications Active Line Trace Frequencies* 128 Hz, 1 kHz, 8 kHz and 33 kHz Passive Power Trace 50 Hz, 60 Hz, <4 kHz Broadband Passive Radio Trace 4 kHz-15 kHz, 15 kHz-36 kHz Sonde Frequencies * 16 Hz, 512 Hz, 640 Hz, 850 Hz, 8 kHz, 16 kHz, 33 kHz Power Source 4 C-Cell Batteries Battery Life Approximately 16 Hours Weight 3.5 lbs. (1,6 kg) Wireless Technology Bluetooth® Class 1 Wireless Range 1093 yards (1000 meters) GPS Average Accuracy Less than 2.5 m (8.2 ft) * 30 user definable frequencies can be set from 10 Hz to 35,000 Hz. Meets FCC Class A and EN 55022 Class A requirements "R" Style IPhone/IPad Monitor This monitor is Compatible with any Ridgid Seesnake Reel. With this monitor you can record your camera inspection and upload it straight to your Iphone/Ipad or USB.  Thus allowing you to email your recording straight to the customer or your supervisor from the job site from your mobile device. Includes: -7" Screen -Transmitter On/Off Switch -Full LED Light Control -Built in Microphone with On/Off Switch -AC/Battery Powered -Battery & Charger Included
