Ridgid 49962 12-r Pipe Threader Die Head, 1-1/2" Bspp, With Std Alloy Rh Dies

US $175.72

Chandler, Arizona, United States
Jun 9th

Open on mobile:
QR code

Ridgid 49962 12-R Pipe Threader Die Head, 1-1/2" BSPP, With Standard Alloy RH Dies Features The 12-R style is available in 1/8”, ¼”, 3/8”, ½”, ¾”, 1”, 1-1/4”, 1-1/2” and 2”. Current-catalog style. All parts are available and supported by Ridgid. Uses standard “drop head” replacement dies. Units ship with dies installed. Equipment is ready to work. Compatible Equipment Die heads require 12-R ratchet and handle to operate. Each size die head is available with several different die options (thread types and die types). The 12-R die heads will fit into the 690 and 700 handheld power threaders. Description With a size range of 1/8” to 2”, the 12-R is Ridgid’s definitive manual threader type for residential and commercial use. The available die head sizes include 1/8”, ¼”, 3/8”, ½”, ¾”, 1”, 1-1/4”, 1-1/2” and 2”. Each size die head is available with several different die options (thread types and alloy types). In additional to being used with the 12-R manual ratchet and handle, the 12-R heads are compatible with several powered threaders, including the model 700 and similar off-brands. Why buy the 12-R? The 12-R is the definitive set for manual threading. With proper accessories, the 12-R dies will also fit into many machine threading setups. If you do not require the 1”-2” range, nor the machine compatibility, check out the lower costs and lightweight 00-R. Don’t see what you require? Contact us. We can fit you with exactly what you need. Die Compatibility Table Note: Your die head will ship with the designated die type and size. This table lists additional dies that can fit in these die heads. The dies are user-replaceable, and take approximately 5 minutes to change out. Thread Type Die Type Size (With TPI) Ridgid Catalog # NPT Alloy RH 1 1/2-11 1/2 37845 NPT High-Speed RH 1 1/2-11 1/2 37890 NPT High-Speed LH 1 1/2-11 1/2 38080 NPT H.S. For Stainless Steel RH 1 1/2-11 1/2 37935 NPT H.S. For PVC RH 1 1/2-11 1/2 70710 NPT HS Reversible RH 1 1/2-11 1/2 49727 NPSM Alloy RH 1 1/2-11 1/2 37980 BSPP Alloy RH 1 1/2-11 66225 BSPT Alloy RH 1 1/2-11 45883 BSPT High-Speed RH 1 1/2-11 66345 BSPT High Speed for Plastic Coated 1 1/2-11 92497 About Ridgid Since 1923, RIDGID has remained the symbol of certainty to dedicated professionals of the expert trades. Every tool that bears the RIDGID brand is engineered to the same high standards of quality, strength, and endurance, as was that first heavy-duty pipe wrench more than 80 years ago. Ridgid covers its products with a lifetime warranty against defects in material or workmanship for the life of the tool. Choosing The Right Thread Type NPT – This is the most common standard in the USA. If you’re not sure what thread you require, it’s likely the NPT. National Pipe Thread Taper (NPT) is a U.S. standard for tapered threads used on threaded pipes and fittings. In contrast to straight threads that are found on a bolt, a taper thread will pull tight and therefore make a fluid-tight seal. In America, William Sellers set the standard for nuts, bolts, and screws which became the National Pipe Tapered Thread (NPT) in 1864. Commonly used sizes are 1⁄8, 1⁄4, 3⁄8, 1⁄2, 3⁄4, 1, 1 1⁄4, 1 1⁄2, and 2 inch, appearing on pipes and fittings by most U.S. suppliers. Sizes smaller than 1⁄8 inch are occasionally used for compressed air, while sizes larger than 2 inches are uncommon, due to the use of alternative methods of joining that are used with these larger sizes. NPTF indicates a “female” thread. NPTM indicates a “male” thread. NPSM - The National Standard Free-Fitting Straight Mechanical Pipe Thread (NPSM) piping convention refers to pipe thread that is not tapered. NPSM pipe threads do not seal as effectively as NPT threads. BSPT and BSPM - The British Standard Pipe (BSP) is a family of standard screw thread types that has been adopted internationally for interconnecting and sealing pipe ends by mating an external (male) with an internal (female) thread and has been adopted as a standard scale used in plumbing fittings, except in the United States where NPT is the standard used. Two types of threads are distinguished: Parallel ('straight') threads, British Standard Pipe Parallel thread (BSPP; originally also known as[1] British Standard Pipe Fitting thread/BSPF and British Standard Pipe Mechanical thread/BSPM), which have a constant diameter; denoted by the letter G. Taper threads, British Standard Pipe Taper thread (BSPT), whose diameter increases or decreases along the length of the thread; denoted by the letter R. A list of 16 thread sizes are defined by the standards, ranging from 1⁄16 to 6. The size number was originally based on the inner diameter (measured in inches) of a steel tube for which the thread was intended, but contemporary pipes tend to use thinner walls to save material, and thus have an inner diameter larger than this nominal size. In the modern standard metric version, it is simply a size number, where listed diameter size is the major outer diameter of the external thread. For a taper thread, it is the diameter at the "gauge length" from the small end of the thread. The taper is 1 to 16, meaning that for each 16 units of measurement increase in the distance from the end, the diameter increases by 1 unit of measurement. UNC (Coarse) and UNF (Fine) (Bolts Only) - The Unified Thread Standard (UTS) defines a standard thread form and series—along with allowances, tolerances, and designations—for screw threads commonly used in the United States and Canada. It has the same 60° profile as the ISO metric screw thread, but the characteristic dimensions of each UTS thread (outer diameter and pitch) were chosen as an inch fraction rather than a millimeter value. The UTS is currently controlled by ASME/ANSI in the United States. The standard designation for a UTS thread is a number indicating the nominal (major) diameter of the thread, followed by the pitch measured in threads per inch. For diameters smaller than 1⁄4 inch, the diameter is indicated by an integer number defined in the standard; for all other diameters, the inch figure is given. This number pair is optionally followed by the letters UNC, UNF or UNEF if the diameter-pitch combination is from the “coarse”, “fine” or “extra fine” series, and may also be followed by a tolerance class. Choosing The Right Die Type Alloy RH - For right hand threading. This is the basic standard for “manual” pipe threading. High Speed RH - For right hand threading. High speed dies are required if using your die head in conjunction with a machine threader. They are made of stronger materials which allow for faster threading. High Speed LH - For left hand threading. High speed dies are required if using your die head in conjunction with a machine threader. They are made of stronger materials which allow for faster threading. LH threading is not a common method. Alloy for JIS RH – Japanese International Standard for right hand threading. British ISO Alloy RH – British standard for right hand threading. Available in metric sizes. Note Ridgid provides thorough solutions for pipe threading. Some die types are not available in all sizes. If you have a selected your required thread/die type, and do not see the size you require, it is because Ridgid does not manufacturer the die/thread/size combination requested. B2E Surplus offers a 90-day warranty on all sales. Warranted to be free from defects in materials and workmanship under normal use and service. Unless otherwise set forth in a quotation or agreed to by B2E Surplus in writing, standard Products are warranted for 90 days from the date of delivery to the buyer. Subject to the exclusions described below, all B2E Surplus products (?Products?) are warranted to be free from defects in materials and workmanship under normal use and service. Unless otherwise set forth in a quotation or agreed to by B2E Surplus in writing, standard Products are warranted for 90 days from the date of delivery to the buyer. EXCLUSIVE REMEDY. In the event that B2E Surplus determines that a Product contains a defect in materials or workmanship, then B2E Surplus, in its sole discretion, will (a) repair the Product, (b) replace the Product, or (c) refund the purchase price of the Product. THIS LIMITED WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE REMEDY OF REPAIR, REPLACEMENT OR REFUND IS BUYER?S SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY. IN NO EVENT SHALL B2E SURPLUS? LIABILITY UNDER THIS WARRANTY EXCEED THE PURCHASE PRICE OF THE PRODUCT GIVING RISE TO THE WARRANTY CLAIM. All Products which are repaired or replaced shall be warranted only for the unexpired portion of the original warranty period. EXCLUSIONS. This warranty does not cover (a) any failures which are not attributable to defects in materials or workmanship, including without limitation, failures caused by accidents, inadequate maintenance, misuse, unauthorized modifications or repairs, improper storage, and normal wear and tear, (b) any consumable parts or accessories, such as cutter blades, nut splitter chisels, punches, dies, chains, wedges, and strands, that are designed to wear over time or through use of the Product, or (c) electronics, motors, batteries, and engines, as these items are warranted by their manufacturer. WARRANTY RETURNS. No Products shall be returned without prior authorization from B2E Surplus. Buyer shall prepay all shipping charges for the return of Products to B2E Surplus? designated service location. LIMITATION OF LIABILITY. IN NO EVENT SHALL B2E SURPLUS BE LIABLE FOR ANY INCIDENTAL DAMAGES, CONSEQUENTIAL DAMAGES, SPECIAL DAMAGES, INDIRECT DAMAGES, LOSS OF PROFITS, LOSS OF REVENUES, OR LOSS OF USE, EVEN IF INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. B2E SURPLUS' LIABILITY FOR DAMAGES ARISING OUT OF OR RELATED TO ANY ORDER IS LIMITED TO THE ORDER PRICE FOR THE SPECIFIC PRODUCT THAT GIVES RISE TO THE CLAIM. TO THE EXTENT PERMITTED BY APPLICABLE LAW, THESE LIMITATIONS AND EXCLUSIONS SHALL APPLY REGARDLESS OF WHETHER LIABILITY ARISES FROM BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING BUT NOT LIMITED TO NEGLIGENCE), BY OPERATION OR LAW, OR OTHERWISE.

“Unit is fully rebuilt (stripped down, sandblasted, repainted and serviced as-needed). The dies are in either "like new" or "new" condition. It includes a 90-day warranty from B2E Surplus.”

Country/Region of Manufacture	United States
MPN	49962
Make	Ridgid
Type	Handheld
Model	49962
