Rigol Dg1022 Awg Function Waveform Signal Generator 20m

US $424.00

Hong Kong, China
Jan 29th

Open on mobile:
QR code

GetOptic RIGOL Function Waveform Generator DG1022 Update to DG1022U 25M Item Description Bidder Attention Please We are a H.K. based optical supplier carrying a full line of high quality products. Good quality but reasonable price always. All our products are manufactured under the strict quality control guidelines established by ISO 9001: 2000 Standards. CE approval covered all of our products, meanwhile most of ophthalmic instruments are qualified with FDA and UL apporval. Features: DDS technology: Output signals become more accurateand stable with lower distortion 2 channels output 5 standard waveforms: Sine, Square, Ramp, Pulse, Noise,and 48 stored arbitrary waveforms 100 MSa/s of sample rate, 14 bits of vertical resolution,4k points of memory depth Intuitionistic user interface, to be easy to use withoutspecification Versatile modulation and variety of waveforms: AM, FM, PM, FSK, Sweep, Burst Versatile input and output: External modulation source, External clock reference(10 MHz), External trigger input, waveforms output, Synchronous Signal Output High accuracy and wide band width frequency counter range up to 200 MHz USB Host, to support USB disk storage Seamless connectivity with DS series digital oscilloscopes: Lossless recurrence of stored waveforms obtained from DS Multi-language user interface, built-in help system Specification: Model DG1022 Standard Waveforms Sine, Square, Ramp, Pluse, Noise and 48 stored arbitrary waveforms Sine 1 ?Hz to 25 MHz Square 1 ?Hz to 5 MHz Pluse 500 ?Hz to 5 MHz Ramp 1 ?Hz to 500 kHz Arb 1 ?Hz to 5 MHz White Noise 5 MHz(-3db) Resolution 1 ?Hz Accuracy Within 90 days: 10 ppm Within 1 year: 20 ppm, 18°C - 28°C Temperature index < 5 ppm/°C Sine Wave Spectral Purity Harmonic Distorion DC to 20 kHz 20 kHz to 100 kHz 100 kHz to 1 MHz 1 MHz to 10 MHz Total Harmonic Distorion DC to 20 kHz0.04% Spurious (non-harmonic) DC to 1 MHz< -70 dBc 1 MHz to 10 MHz< -70 dBc + 6 dB/octave Phase Noise 10kHzOffset –115 dBc / Hz, typical Square Wave Characteristic Rise/Fall Time < 20 ns (10% to 90%) Overshoot < 2% Duty Cycle 1?Hz(include)to 3MHz(include) 3MHz(non-include)to 4MHz(include) 4MHz(non-include)to 5MHz(include) Asymmetry(below 50% Duty Cycle) 1% of the period + 20ns Jitter 6ns + 0.1% of the period Pulse Wave Characteristics Pluse Bandwidth 2000s max,20ns min,10ns min resolution Overshoot < 2% Jitter 6ns + 100 ppm of the period Arb Wave Characteristics Waveform Length 2 to 4k points Amplitude Accuracy 14 bits (including sign) Sample Rate 100MSa/s Minimum Rising /Falling Time 35ns Jitter (RMS) 6 ns + 30ppm Non-Volatile Storage 4 waveforms Output Characteristics Amplitude
