Rigol Ds1102d Mixed Signal Oscilloscope

US $891.00

HK, Hong Kong
Jan 29th

Open on mobile:
QR code

A true mixed signal oscilloscope with 16 channel Logic Analyzer 1 GSa/s maximum Real-time Sample Rate and 1 Mpts of memory depth Bandwidth - 100MHz Extensive set of trigger modes including: Edge, Video, Pulse Width, Slope, Alternate 5. 64 k TFT Color LCD, bright and vivid waveform display Compact design to save your desktop space 1 GSa/s maximum real-time sample rate, 25 GSa/s maximum equivalent-time sample rate 1Mpts long Memory Depth Ultra compact design: 303mm x 154mm x 133mm (WxHxD) 64 k TFT color LCD, bright and vivid waveform display Adjustable bigger sensitivity: Effactively filter noise from bigger signal and avoid false trigger 20 automatic measurements Cursor measurements: Manual, Track and Auto Measure modes 10 waveforms, 10 setups, BMP and CSV storage Math functions:+, -, x, FFT, Invert Special digital filter and waveform recorder Built-in hardware frequency counter Standard interface: USB Device, USB Host, RS-232 Standard configuration: PassIFail test, effectively avoid electromagnetic interference by using photoelectricity-isolation Multi-language user interface, built-in help system Direct print to PictBridge compatible printers via USB Device interface SPECIFICATIONS Model DS1102D DS1052D Bandwidth 100 MHz 50 MHz Channels Dual Channels + External Trigger Real-time Sample Rate 1GS/s Equivalent Sample Rate 25 GSa/s 10 GSa/s Memory Depth Channel Mode Sample Rate Normal Memory Long Memory Single Channel 1 GS/s 16 kpts N/A Single Channel 500MS/s Or lower 16 kpts 1 Mpts Dual Channel 500MS/s Or lower 8 kpts 512 kpts Rise Time 3.5ns 7ns Time Base Range 2 ns/div to 50 s/div 5 ns/div to 50 s/div Trigger Modes Edge, Video, Pulse Width, Slope, Alternative Input Impedance 1 M? || 15 pF Vertical Sensitivity 2 mV/div to 10 V/div Vertical Resolution 8 bits Input Coupling DC, AC, Ground Maximum Input Voltage 400 V (DC + AC peak) Roll Range 500 ms/div to 50 s/div Cursor Measurements Manual, Track and Auto Measure modes Math Add, Subtract, Multiply, FFT Storage USB Device, USB Host, RS-232, P/F Out (Isolated) Display 5.6"TFT (64K, Color LCD), 320 x 234 Power Worldwide Use, 100 – 240 V / 50 VA Max Weight 2.4 kg

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RIGOL
Country/Region of Manufacture	China
Model	DS1102D
Voltage	110/220
Type	Digital
Warranty	36
Bandwidth	100MHz - 349MHz
Features	desktop, mixed-signal
Channels	2, with 16 channel logic analyzer
Storage Capacity	1 MB
Sample Rate	1GSa/s - 1.9GSa/s
Screen Size	5.6" TFT display
