Rigol Vb1020 Vswr Bridge

US $350

Saint Marys, Georgia, United States
Nov 6th

Open on mobile:
QR code

Rigol VB1020 VSWR Bridge Product Features Product Description VSWR Bridge VB1020 with 1 MHz to 2 GHz measuring range, is used in combination with the RIGOL DSA series spectrum analyzer to measure S11-related parameters (such as return loss, reflection coefficient and VSWR). VB1020 provides three N female connectors as shown in the figure below. IN: Signal input terminal. Here the signal generator or the output terminal of the tracking generator of the spectrum analyzer is connected. OUT: Signal output terminal. Here the wattmeter or the RF input terminal of the spectrum analyzer is connected. DUT: Here the device under test is connected. Measurement Connection Connect VB1020 to the spectrum analyzer as shown in the figure Connect the spectrum analyzer Use 2 adaptors (n male-N male) to connect the output terminal of the tracking generator and the RF input terminal of the spectrum analyzer to the IN and OUT terminal of the VSWR bridge respectively Connect the device under test Do not use cables or adaptors as far as possible to avoid additional reflection. Typical Applications Measurement of the S11-related parameters of the filter, amplifier, mixer, etc. Resonant frequency and VSWR tests of the antenna. Shipping: We ship to the lower 48 states only. No International Shipping. We cannot ship to Puerto Rico, Alaska, Guam, Hawaii, US territories, APO/FPOs, PO Box. We cannot combine shipping, and there is no local pickup. Additionally, our carriers do not provide shipping to certain zip codes. In order to ensure delivery availability to your home please message us with your zip code prior to ordering. Please send us email right away after the payment if you wish to include "Deliver on Weekend" option. During month of December please have in mind that for some items our manufacters are overloaded and this may cause shipping time 3-5 business days. Tracking: You can track your order by clicking the "View order details" link on the listing that you're receiving. Please allow up to three days for order processing. Refunds/Returns: We work with all of our customers to ensure that they are getting a positive experience. Refunds are available for returned items. We accept returns within 30 days from the date you receive your item. IF you do have a concern or want to return an item please CONTACT US before opening a return case. Return cases negatively affect selling accounts and we will professionally handle your concerns/returns Feedback/Contact Info: Communication is KEY to helping us give you the best experience. The best way to contact us is through eBay messages, we work very hard to ensure that our customers are taken care of. As an eBay selling company feedback is our life blood. Please contact us with any concerns or problems that you encounter before leaving negative/neutral feedback! We will do our best to turn any less than satisfactory experience into a positive one. If you are happy with our transaction please leave us positive feedback. We Always Provide The BEST SERVICE!
