Robertshaw Temperature Regulator Rt-1009 Series Reverse Valve 2.5" 70-100degf

US $140

Willowbrook, Illinois, United States
Jun 9th

Open on mobile:
QR code

Robertshaw Temperature Regulator RT-1009 Series Self-Actuated Valve 2.5 inch Reverse Acting 70 to 100 degF Up for sale is a new Temperature Regulator RT-1009 Series FEATURES 1. Large two-ply, seamless bellows used for long life and extra power. 2. Valve can alternately be manually positioned or thermostatically operated. 3. Over-temperature protection is standard feature. 4. Chevron "Lifetime" stem packing made of Teflon* or ETP Rubber U-Cup for water service. 5. Quick-detach valve stem construction permits easy valve change. 6. Sturdy construction with cast iron frame. 7. High quality indicating thermometer on regulators RT-1009-Bl and RT-1009-Cl 8. Variety of sensing bulb forms and materials. (See inside pages). 9. Valves in wide range of sizes, actions, styles, materials, etc. for many types of service. (See inside pages). 10. Capillary selection (See inside pages). 11. Setpoint adjustment wheel. GENERAL Without need for external power, Robertshaw Self-Actuated Temperature Regulators (SATR) offer final control of the temperature of a liquid, an air space or flow, or gas flow for domestic, equipment, process, space, etc. on heating or cooling service. The SATR sensing bulb is installed in the medium being controlled while the SATR valve is located on the supply line of the medium used as the heating (steam, hot water) or cooling (water, ethylene glycol, brine) agent. The SATR regulates the heating or cooling medium flow to maintain the desired temperature at the sensing bulb location. RT-1009 SERIES The RT-1009 series is especially designed for those applications where a fully opened or a fully closed valve (or full by-pass or cooling flow) is desirable regardless of the setpoint or the temperature at the sensing bulb. The RT-1009 series stem can be manually cranked up or down to obtain the desired valve position on either a two-way or three-way valve. When automatic (thermostatic) control, at the previous setpoint setting is again desired, the stem can be cranked back to where the stem pointer indicates "THERMOSTATIC." The RT-1009series has a hand wheel for setpoint adjustment that is completely independent of the manual override crank. This unit is being SOLD AS IS, WHERE IS WITH NO WARRANTY, and EXPRESSED WRITTEN OR IMPLIED. Payment: PayPal. WE DO NOT SHIP ITEMS. IT IS UP TO THE WINNING BIDDER TO PICK UP AT OUR LOCATION IN CHICAGO LAND. ALL SALES ARE FINAL.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Robertshaw
Country/Region of Manufacture	United States
Model	RT-1009
