Roboteq Fim2360s 1x120a 60v Robot Controller

US $667.58

Swanton, Vermont, United States
Jul 13th

Open on mobile:
QR code

Description RoboteQ FIM2360S Robot Controller Capable of driving one AC Induction motor up to 120A Continuous Amps per Channel: 80 Max Voltage: 60V USB, Serial, 0-5V Analog, or Pulse (RC radio) command modes The RoboteQ FIM2360S 1x120A 60V Robot Controller is a features-packed, high-current controller capable of driving one AC Induction motor up to 120A. The controller can operate in one of several modes in order to sense the rotor position and sequence power on the motors’ 3 windings in order to generate smooth continuous rotation. The controller also uses the Encoder information to compute speed and measure travelled distance inside a 32-bit counter. The motors may be operated in open or closed loop speed or torque modes. The FIM2360S features several Analog, Pulse and Digital I/Os which can be remapped as command or feedback inputs, limit switches, or many other functions. The FIM2360S accepts commands received from an RC radio, Analog Joystick, wireless modem, or microcomputer. Using CAN bus, up to 127 controllers can be networked at up to 1Mbit/s on a single twisted pair. Numerous safety features are incorporated into the controller to ensure reliable and safe operation. The controller's operation can be extensively automated and customized using Basic Language scripts. The controller can be configured, monitored and tuned in realtime using a Roboteq’s free PC utility. Specifications Motor Type: AC Induction Max Voltage: 60 Number of Channels: 1 Direction: Forward/Reverse Max Amps per Channel: 120 Continuous Amps per Channel: 80 ON Resistance (mOhm): 1.25 Power Connections: Fast on Field Oriented Control (FOC): Yes Analog: Yes RS232: Yes USB: Yes CANbus: Yes RC Pulse: Yes MicroBasic Scripting: Yes Control Loop (ms): 1 Regenerative braking: Yes Max Analog Inputs: 8 Max Digital Inputs: 10 Digital Outputs: 4 Max Pulse Inputs: 6 Encoder: Yes Cooling Conduction plate Applications Automatic Guided Vehicles Small Electric Vehicles, Electric Bikes Terrestrial and Underwater Robotic Vehicles Police and Military Robots Hazardous Material Handling Robots Animatronics What's Included 1 x RoboteQ FIM2360S 1x120A 60V Robot Controller Dimensions 140mm x 140mm x 25mm Weight: 250g Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RoboteQ
Type	RoboteQ
MPN	FIM2360S
UPC	Does not apply
