Roboteq Sdc2160 - 2x20a, 7v-60v Robot Controller

US $275.00

Swanton, Vermont, United States
Sep 2nd

Open on mobile:
QR code

Description Dual 20A, Brushed DC motor controller High-performance 32-bit microcomputer Number of channels: 2 Operating voltage: 7V-60V DC Cables sold separately This is the RoboteQ SDC2160 - 2x20A, 7V-60V Robot Controller. It is designed to convert commands received from an RC radio, analog joystick, wireless modem, PC (via RS232 or USB) or microcomputer into high voltage and high current output for driving one or two DC motors. Fitting a very compact 70x70mm board, and designed for maximal ease-of-use, it is ready to use in minutes. The controller features a high-performance 32-bit microcomputer and quadrature encoder inputs to perform advanced motion control algorithms in Open Loop or Close Loop (Speed or Position) modes. It features several analog, pulse and digital I/Os which can be remapped as command or feedback inputs, limit switches, or many other functions. For mobile robot applications, the controller's two motor channels can either be operated independently or mixed to set the direction and rotation of a vehicle by coordinating the motion of each motor. Specifications Max current: 1min: 2 x 20 A 3 min: 2 x 15 A 1h: 2 x 10 A Surge current: >50A Serial interface: RS232 Standard and TLL Serial, 115200 bauds Operating temperature: 40ºC to +85ºC heat sink temperature Dimensions Controller size: 2.6'' (70mm) wide x 2.6'' (70mm) tall x 0.75'' (19mm) Weight: 80g Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RoboteQ
Type	RoboteQ
MPN	SDC2160
UPC	Does not apply
