Rockwell 14" Lathe Operation, Service, & Repair, Manual Later Version *162, US $220 – Picture 0
Rockwell 14" Lathe Operation, Service, & Repair, Manual Later Version *162, US $220 – Picture 0

Rockwell 14" Lathe Operation, Service, & Repair, Manual Later Version *162

US $220

  • Goddard, Kansas, United States
  • Jun 2nd
Open on mobile:
QR code
Rockwell 14" Lathe Later version w/ spindle brake on top  Operation, Service, & Repair Manual For models: 14" w/spindle brake on top Description: This is an Operation, Service, and Repair Manual for the Rockwell 14" Lathe later version.  It contains instructions on the Installation, Operation, Controls, Adjustments, Lubrication, Maintenance, and Repairs, and Exploded Parts Views. There is no parts list in this manual.  The manual has 41 pages.  To inspect the quality of the manual, to view the Table of Contents and to view select pages,  please click on the gallery images above to enlarge. Includes sections on: Installation Operation Lubrication Lubrication Chart Controls Quick Change Gear Box Carriage Tailstock Variable Speed Drive Service Adjustments Replacing Shear Pins Belt Adjustments Clutch Adjustments Maintenance & Repairs Including: Headstock Belt Drive System Quick Change Gear Box Apron Number of pages: Approx 41 Condition: Very Good Publication date: January 1971 Publication No.:  PM-414-03-651-5003 Added Notes: Due to competitors making copies of these manuals for resale, select                             pages have been lightly watermarked to discourage this practice. About This Manual:    This is a high quality reproduction manual which has been scanned with a high resolution scanner.  Each page is then digitally edited in Photoshop to remove grease marks, fingerprints, writing, and other imperfections that the original manual may have had.  It is then printed on 24 lb heavy paper and 65 lb cardstock for the covers with a 600 DPI LaserJet printer.  The result is a clean and durable manual which many times is better than the original and should last many years in your shop. Questions? Email: eugene@fabersurplus.com Phone: 316-210-4079 after 11:00 am Central Time Ships USPS First Class Free or Upgrade to Priority Mail for faster delivery. Sales tax charged for Kansas sales. See my for more manuals
