Rohde & Schwarz Fsh-z2 Vswr-bridge

US $550.00

  • Mariefred, Sweden, Sweden
  • Jan 29th
Open on mobile:
QR code
Used R&S VSWR-Bridge FSH-Z2 in very nice and good working condition with only some minor signs of use. Key Facts: Scalar transmission and reflection measurements with VSWR bridge The R&S®FSH with built-in tracking generator rapidly determines the transmission characteristics of cables, filters, amplifiers, etc, with a minimum of effort. When equipped with the R&S® FSH-Z2/-Z3 VSWR bridge (10 MHz to 3 GHz/6 GHz), the R&S®FSH can also measure the matching (return loss, reflection coefficient, or VSWR) of an antenna, for example. The bridge is screwconnected directly to the R&S®FSH’s RF input and tracking generator output without involving cumbersome, extra cabling. Specification: VSWR Bridge and Power Divider FSH-Z2 Frequency range 10 MHz to 3 GHz Impedance 50 Ohm VSWR bridge Directivity 10 MHz to 1 GHz    typ. 30 dB 1 GHz to 3 GHz    typ. 25 dB Directivity, corrected (option FSH-K2) 10 MHz to 3 GHz    typ. 43 dB Return loss at test port   typ. 20 dB Return loss, corrected option FSH-K2  typ. 35 dB Insertion loss     typ. 9 dB Power divider Return loss at test port   typ. 20 dB Connectors Generator input/RF output   N male Test port     N female Control interface    7-contact connector (type Binder) Calibration standards Short/open     N male 50 O load     N male  Impedance    50 O  Return loss up to 3 GHz  >43 dB  Power-handling capacity  1 W General data Power consumption    500 mW (nominal) Dimensions (W x H x D)    169 mm x 116 mm x 30 mm Weight      485 g I will send worldwide. The shipping cost when sent as standard post office parcel will be 45 USD without insurance (only trackable within Europe). If you prefer, I could also send by UPS or Fedex, but the cost will then be higher. Insurance could be added with additional cost.
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Very good working condition with only some minor signs of use.”
