Rohde & Schwarz Fsh6 R&s 6.06 Handheld Spectrum Analyzer W/ Preamplifier Fsh

US $4,995.00

  • Toledo, Ohio, United States
  • Jan 29th
                                                              Content on this page requires a newer version of Adobe Flash Player.                      The Following Items Are Included: Rohde & Schwarz FSH6 6.06 Handheld Spectrum Analyzer (BC# 18224) w/ Options Preamplifier Armored Test Port Cable (2) BNC To BNC Cables AC Adapter/Charger User Manual On CD-ROM Carrying Case (G)     BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration!   Rohde & Schwarz FSH6 6.06 Handheld Spectrum Analyzer Software Version: V14.00   Installed Options: - Preamplifier   Frequency Range: 100 Khz to 6.0 GHz   Includes Carrying Case & Accessories As Listed Above!     Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty     Rohde & Schwarz FSH6 Handheld spectrum analyzer 100 kHz - 6 GHz, RBW 100 Hz -1 MHz, LCD color display, preamplifier   The Rohde & Schwarz FSH6 spectrum analyzer is a wide band, very sensitive receiver. It works on the principle of "super-heterodyne receiver" to convert higher frequencies (normally ranging up to several 10s of GHz) to measurable quantities. The received frequency spectrum is slowly swept through a range of pre-selected frequencies, converting the selected frequency to a measurable DC level (usually logarithmic scale), and displaying the same on the CRT of the Rohde & Schwarz FSH6. The CRT displays received signal strength (y-axis) against frequency ( x-axis). Some applications for Rohde & Schwarz FSH6 Spectrum Analyzers include Site Monitoring: Verify that the frequency and signal strength of your transmitter is accurate. Interference: Before a system is installed you use a Rohde & Schwarz FSH6 spectrum analyzer to verify that the frequencies (you plan to use) are not occupied or if the presence of a very strong signal will interfere with your new setup. Interference can be created by a number of different situations. Other tests that utilize the Rohde & Schwarz FSH6 spectrum analyzer features include antenna isolation, co-channel interference, adjacent channel power, occupied bandwidth, intermodulation, microwave or satellite antenna alignment, and characterization of components. The FSH is the ideal spectrum analyzer for rapid, high-precision, cost-effective signal investigations. It provides a large number of measurement functions and so can handle anything from the installation or maintenance of a mobile radio base station up to on-site fault location in RF cables as well as development and service -an extensive range of applications. Due to its excellent characteristics, the FSH is used on board the International Space Station (ISS) for distance-to-fault measurements on RF antenna cables.   Features Frequency range 100 kHz to 6 GHz Internal preamplifier with frequency range from 100 kHz to 6 GHz Displayed average noise level typ. -135 dBm (RBW 100 Hz) 0.5 dB typ. level accuracy up to 6 GHz Resolution bandwidths 100 Hz to 1 MHz, 1 and 3 steps Wide range of detectors: sample, max/min peak, auto peak, RMS   The Rohde & Schwarz FSH Series is the ideal spectrum analyzer for rapid, high-precision, cost-effective signal investigations. It provides a large number of measurement functions to handle anything from the installation or maintenance of a mobile radio base station, to on-site fault location in RF cables, to development and service. Model Frequency Range Tracking Generator Output Preamp Resolution Bandwidth FSH6 100 kHz to 6 GHz None Yes 100 Hz to 1 MHz   TDMA Power Measurements The FSH performs time-domain power measurements within a timeslot of TDMA (time division multiple access) methods. All the settings required for the GSM and EDGE standards are predefined to make these measurements easier for the user. In addition, up to five user-definable instrument setups can be loaded into the FSH using the FSH View software. Channel-Power Measurements The channel-power measurement function is for determining the power in a transmission channel specified by the user. After a few preliminary settings have been made, a single keystroke starts the FSH's spectrum measurement inside the channel, using a resolution bandwidth that is small relative to the channel bandwidth. The FSH then integrates the measured values indicated by the trace to obtain and display the total power. All the settings required for the digital mobile radio standards 3GPP WCDMA, cdmaOne, CDMA2000 1x are predefined ready for use. The FSH also takes the characteristics of the selected display mode (lin or log), the selected detector and the resolution bandwidth into account so that the result accuracy is comparable to that obtained with a thermal power meter. Measurements on Cables (distance-to-fault) For rapid and accurate determination of the distance to any faults in an RF cable. Distance-to-fault measurements using the VSWR Bridge FSH-Z2 give an immediate overview of the state of the device under test (return loss and distance). The marker-zoom function allows detailed analysis of faults with a resolution of up to 1024 pixels. Requires FSH313/323/626 (with built-in tracking generator), option FSH-B1 (distance-to-fault measurement) and FSH-Z2 (VSWR bridge and power divider). Scalar Network Analysis The FSH313/323/626 (with built-in tracking generator) can be used to determine the transmission characteristics (i.e. attenuation or gain) of two ports such as cables, filters, amplifiers, etc, rapidly and with a minimum of effort. A simple calibration procedure compensates for the attenuation introduced by measurement cables or any attenuators used for amplifier measurements. When the VSWR Bridge FSH-Z2 is attached, the matching (return loss or VSWR) at the input or output of two ports can be determined as well as their transfer function. The bridge is screwed directly onto the RF input and tracking generator output, and no extra or cumbersome cabling is required.     Frequency R&S FSH6 Frequency range 100 kHz to 6 GHz Reference Frequency Aging 1 ppm/year Temperature drift 0 °C to +30 °C 2 ppm +30 °C to +50 °C In addition 2 ppm/10°C Frequency counter Resolution 1Hz Counter Accuracy S/N > 25 dB ± (frequency x reference frequency error) Frequency Span model .06/.26 0 Hz, 100 Hz to 6 GHz Spectral Purity SSB phase noise f = 500 MHz, +20 °C to +30 °C   30 kHz from carrier <–85 dBc (1 Hz) 100 kHz from carrier <–100 dBc (1 Hz) 1MHz from carrier <–120 dBc (1 Hz) Sweep Time span=0 Hz 1 ms to 100 s span>0 Hz 20 ms to 1000 s, min. 20 ms/600 MHz Bandwidths Resolution bandwidths (–3 dB) model .03/.23, model .06/.26/.18 in addition 100 Hz, 300 Hz Tolerance
Condition:
Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...
Model FSH6
Analyzer Type Spectrum Analyzers
Manufacturer Rohde Schwarz
Unit Type Complete Systems & Mainframes
