Rohde & Schwarz Fsig13 Signal Analyzer , 9khz-13ghz

US $7,800.00

Fremont, California, United States
Jan 29th

Open on mobile:
QR code

Rohde & Schwarz FSIG13 Signal Analyzer , 9KHz-13GHz This sale is for one used Rohde & Schwarz FSIG13 Signal Analyzer , 9KHz-13GHz. It passed all self tests, it looks at good working condition. Next calibration due on 08/31/2013. General Description on Rohde & Schwarz FSIG13 The Rohde & Schwarz FSIG13 , 13 GHz Signal Analyzer provides in a single unit comprehensive and easy-to-use measurement functions in the, frequency domain, time domain, modulation domain and code domain (cdma One forward channel). In the frequency domain, the FSIG 13 measures intermodulation and harmonics with great accuracy. The high 3rd-order intercept point in conjunction with the extremely low noise floor yields a wide intermodulation-free dynamic range and ensures reliable performance of even sophisticated measurements like spurious measurements. The maximum input frequency of 13 GHz allows even out-of-band spurious measurements. In the time domain, the FSIG 13 features all modern capabilities of burst analysis in TDMA systems; gate functions, trigger delay and integrated RF trigger in conjunction with a short sweep time of 1 µs ensure precise measurement of the timing characteristics of mobile radio systems. In the modulation domain, the integrated vector signal analyzer provides diverse measurements on GSM, EDGE, IS-136, cdmaOne, W-CDMA/ 3GPP signals. These convenient presettings make it superfluous for the user to spend valuable time in looking up specifications and go towards enhancing the measurement reliability. An optional application firmware FSIQ-K71allows power measurement in the 64 Walsh code channels of a cdmaOne signal (forward channel). The results can be output numerically or displayed as a bargraph. Features Frequency range: 9 kHz to 13 GHz. Resolution bandwidth: 1 kHz to 10 MHz in 1/2/3/5 steps. 5-pole resolution filters with high selectivity. Displayed average noise floor typically -130 dBm in 1 kHz bandwidth. Third-order intercept +22 dBm. Phase noise -150 dBc(1 Hz) at 5 MHz offset. 75 dB ACPR dynamic range for W-CDMA (4.096 MHz integration BW). Total level uncertainty: <1 dB up to 2.2 GHz, <1.5 dB up to 7 GHz. RMS detector for high-precision power measurements irrespective of waveform. Fast time domain analysis with 1 µs zero span sweep time. Integrated broadband vector signal analyzer for GSM, EDGE, IS-136, cdmaOne, W-CDMA and 3GPP signals with versatile result display: I and Q signal, magnitude and phase, vector and constellation diagrams, tabular output with numerical values of modulation errors and demodulated bit sequence. Display: 24 cm colour diplay TFT (9.5"). Options Hardware. FSE-B13, 1-dB attenuator. FSE-B16, Ethernet Interface. FSE-B17, 2nd IEC/IEEE Bus Interface. FSE-B22, Increased level accuracy up to 2 GHz. FSIQ-B70, DSP and IQ memory extension 2x 512 k.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Model	FSIG13
Analyzer Type	Spectrum Analyzers
Manufacturer	Rohde & Schwarz
Unit Type	Complete Systems & Mainframes
