Rohm - 3mt , 2.362 Inch Head Dia, 1100 Lbs. Caty, Live Center , German Made,

US $320

  • Grayson, Georgia, United States
  • Jun 9th
Rohm - 3MT Taper Shank, 2.362 Inch Head Diameter 1100 Lbs. Capacity Live Center 5,000 Max RPM, 1.661 Inch Long Case, 63/64 Inch Point Diameter, 1.221 Inch Point Length, 0.005 mm Accuracy, 1,100 Lbs. Maximum Workpiece, 6.319 Inch Overall Length, Standard Point     Specs Shank Type Taper Shank Taper Size 3MT Maximum Workpiece Weight (Lb.) 1100.00 Maximum Workpiece Weight (kg) 500.00 Point Style Standard Point Diameter (mm) 25.00 Point Diameter (Decimal Inch) 0.9843 Point Length (mm) 31.00 Point Length (Decimal Inch) 1.2210 Load Capacity (Lb.) 500.00 Head Diameter (Decimal Inch) 2.3620 Head Length (Decimal Inch) 1.6610 Overall Length (Decimal Inch) 6.3190 Gage Line Diameter (mm) 23.83 Point to Gauge Line (mm) 79.50 Included Angle ( ) 60.00 Bearing Type Triple Bearing Accuracy (mm) 0.0050 Maximum RPM 5000 Material Tool Steel Carbide-Tipped (Yes/No) No
