Roland Mdx-40a Engraving Machine

US $8,840.00

Auckland, default, New Zealand
Feb 28th

Open on mobile:
QR code

The Roland MDX-40A 3D milling machine is an affordable, easy-to-use prototyping solution that supports a wide range of materials including resin. A new optional rotary axis unit is available, supporting larger materials. We bought this machine last year, but rarely used. All the software and accessories will be provided together. Specification: MODEL MDX-40A Acceptable materials Resins such as chemical wood and modeling wax (metal not supported) X, Y, and Z strokes 12 (X) x 12 (Y) x 4-1/8 (Z) in. (305 (X) x 305 (Y) x 105 (Z) mm) Distance from spindle tip to table Maximum 123 mm (4-13/16 in.) Table size 12 (W) x 12 (D) in. (305 (W) x 305 (D) mm) Loadable workpiece weight 8.8 lb (4 kg) XYZ-axis motor Stepping motor Feed rate XY-axis: 0.0039 to 1.9 in./s (0.1 to 50 mm/sec.), Z-axis: 0.0039 to 1.1 in./s (0.1 to 30 mm/sec.) Software resolution NC-code: 0.000039 in./step (0.001mm/step), RML-1: 0.00039 in./step (0.01 mm/step)(RML-1) Mechanical resolution 0.00008 in./step (0.002 mm/step)(Micro-step) Spindle motor Brushless DC motor, Maximum 100 W Spindle rotation 4500 to 15000 rpm Tool chuck Collet Interface USB (compliant with Universal Serial Bus Specification Revision 1.1) Power supply Voltage and frequency AC100 to 240 +/-10%, 50/60 Hz Required power capacity 2.1 A Power consumption Approx. 210W Acoustic noise level No-load operation: 56 dB (A) or less, Standby: 42 dB (A) or less Dimensions 26-3/8 (W) x 29-15/16 (D) x 21-13/16 (H) in. 669 (W) x 760 (D) x 554 (H) mm Weight 143.3 lb (65 kg) Operation temperature 41 to 104°F (5 to 40°C) Operation humidity 35 to 80% (no condensation) Included items Power cord, power plug adapter, USB cable, collet, Z0 sensor, hexagonal wrench, hexagonal screw drivers, spanners, Roland System Requirements for Inlcuded Software OS Windows Vista®(32bit edition) or Windows® XP (32bit edition) and Internet Explorer 6.0 or later CPU Pentium® 4, 2.4GHz or faster recommended RAM 1GB or more recommended Free hard-disk space 20MB or more recommended Video card and monitor A resolution of 1024 x 768 or more recommended, video card compatible with OpenGL recommended, and at least 16-bit

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Roland
Country/Region of Manufacture	New Zealand
Model	MDX-40A
