Rotary Table 4" 100mm Horizontal Vertical Mt2 Bore Model Milling Machine 3 Slot/

US $88.32

DELHI, DELHI, India
Jul 23rd

Open on mobile:
QR code

GURUNANAK INTERNTIONAL Rotary Table 4" 100mm Horizontal Vertical MT2 Bore Model Milling Machine 3 Slots Product details : High Precision and Smooth Rotation of Hand wheel. Table Diameter Is 105 mm, Height 50 mm Vertical center height 75 mm Re settable dial one turn = 5 degrees table graduated 360 degrees Center Has a MT-2 Taper. Quick Release System for Manual Indexing. And Has 3 Tee Slots. Description: A Precision work positioning device used in metalworking, enabling the operator to drill or cut work at exact intervals around a fixed axis. Rotary tables are most commonly mounted "flat", with the table rotating around a vertical axis, in the same plane as the cutter of a vertical milling machine. An alternate setup is to mount the rotary table on its end (or mount it "flat" on a 90° angle plate), so that it rotates about a horizontal axis. In this configuration a tailstock can also be used, thus holding the work piece "between centers." Application: Horizontal/Vertical Rotary Tables are extremely useful accessories for a milling machine. Simple to operate, they allow easy work handling and have many varied applications including: Milling : Milling curved profiles and angled faces relative to a centre line. Drilling or milling to polar co-ordinates and, when mounted vertically with a tailstock they can be used to machine shafts or spindles. The versatile units can also be used on drilling, boring or slotting machines permitting an even greater range of operations. -Machining - To establish the initial work piece position simply loosen the zero Collar locking handle and rotate the zero collar anti-clockwise for about half A turn. The worm is now disconnected from the worm wheel drive, the table is Free to turn independently to the crank handle and the work piece may now be Accurately aligned. To re-engage simply turn the zero collar in the clockwise Direction and re-tighten the locking handle. Rotary table uses: To machine spanner flats on a bolt To drill equidistant holes on a circular flange. To cut a round piece with a protruding tang To create large-diameter holes, via milling in a circular tool path, on small milling machines that don't have the power to drive large twist drills (>0.500"/>13 mm) To mill helices To cut complex curves (with proper setup) To cut straight lines at any angle Precision Mini Rotary Table 4 Inch or 100 mm is manufactured from Seasoned casting Vertical center Height : 2-1/16" Hand Wheel can be set to Zero Hand Wheel Graduated in 10 Min Divisions In 3 Slots so you can put you Chuck on its easily. 3 T Slots for fixing work to easily clamp chucks Can be used both Vertically & Horizontally. 5mm Diameter with 14x1mm Thread Payment Policy Paying with us is very easy through PayPal.Your order may be subject to import duties and taxes, which are charged once your package reaches your country, We are not liable for the same. Shipping Policy Your product will be shipped within 1-3 Business days after receiving payments, Via Fedex/DHL/Aramex/My Pacco or India Post with Tracking facility. We ensure the product reaches you at the earliest. Please provide your Correct Address & telephone no, as the shipping company might need it at the time of delivery.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Custom Bundle	No
MPN	Does Not Apply
Setting Position	Horizontal/Vertical
Cross-Slide	No
Tilting	No
Brand	Unbranded
Operation	Manual
UPC	Does not apply
