ROYAL 10522 Spring Type Live Center-Overall Length:3-15/16', US $320 – Picture 0
ROYAL 10522 Spring Type Live Center-Overall Length:3-15/16', US $320 – Picture 0

Royal 10522 Spring Type Live Center-overall Length:3-15/16'

US $320

  • Duncan, South Carolina, United States
  • Jun 6th
Open on mobile:
QR code
Features ±0.00005" TIR guaranteed. Ultra low-profile body provides outstanding tool clearance. Unique spring-loaded design compensates for thermal expansion of the workpiece by allowing the point to slide axially as the part grows. A series of heavy disk springs keep the point firmly seated in the center-hole of the workpiece. Dual roller bearings provide solid radial load capacities. Axial loads are handled by a special thrust bearing located between the point and springs. Body and point are hardened for wear resistance and long life. Bearings are protected from coolant and chips by a neoprene seal. Extended point provides tool clearance for CNC applications. Notes Multiple Point Styles To Suit AllApplications Available, Please Call Product Specifications Product Specifications Weight 0.40000 Brand ROYAL Model # 10522 Taper 2 MT Weight Of Workpiece 540 lbs. Thrust Load 150 lbs. Maximum Rotational Speed 5,000 RPM Point Type Standard Comp Load Rate 690 lbs. Gage Line Length 2-9/16" Length From Gage Line To Front of Center .700" Length of Taper To Back of Head 3-1/16" Morse Taper 2 Overall Length 3-15/16" Point Angle 60° Point Diameter 3/8" Point Length 7/8" Spring Travel 0.11" TIR Repeatability ±0.00005" Country of Origin UNITED STATES OF AMERICA Powered by Solid Commerce The All-in-One Listing, Inventory & Order Management Solution for Online Merchants
