Rti Rcm-12 Relay Control Module W/ 12 Ports

US $120

Houston, Texas, United States
Jan 29th

Open on mobile:
QR code

The RCM-12 Relay Control Module provides twelve addressable relays for controlling everything from amplifiers to window coverings. Adjustable device IDs allow easy expendability for larger projects. With an IR input and a discrete code set, each relay can be triggered from RTI in-wall or handheld controllers, control processors or even third-party infrared repeater systems. Each relay can be used in a normally open or normally closed configuration. With twelve individually addressable relays and an adjustable device ID, the RCM-12 Relay Control Module is flexible and expandable enough to provide relay control for projects of any size. Each relay has a removable terminal block with connections for either a normally open or normally closed configurations. An IR input allows the RCM-12 to be triggered from many different sources, including RTI in-wall or handheld controllers, control processors or third-party infrared repeater systems. IR commands trigger open and close functions as well as adjustable hold times for momentary relay operation. Twelve individually addressable relays. Relays capable of switching up to 28VDC@5A. Discrete set of IR codes and an IR input allows relays to be triggered from virtually any IR programmable system. Control port for connection to RTI Control Processors. Relays can be used in a normally open or normally closed configuration. Relays create a “dry contact”. Programmable momentary relay hold times. Adjustable device ID for installations that require more than twelve relays. Sturdy steel construction. 12VDC power supply included. Power +12VDC, 1.25A Infrared Input Compatible with industry-standard repeaters and receivers Relays Twelve, 28 VDC@5A Control Port RS-485/IR/Pwr Device IDs Ten , Rotary switch Enclosure Formed steel, black powder coating Mounting Wall-mount or free standing
