Ry-f600 Ftth Fusion Splicer ( Optical Fiber Cleaver Automatic Focus Function)

US $2,199.00

shenzhen, China
Jan 29th

Open on mobile:
QR code

RY-F600 FTTH Fusion Splicer include Optical Fiber Cleaver automatic focus function Description RY-F600 FTTH Fusion Splicer include Optical Fiber Cleaver automatic focus function Features:Digital fusion splicer with automatic focus function Fiber core can be display clearly Single X or Y view and X & Y view simultaneously Auto detect cleaved endface fault Display fiber cleaved and offset angle Display core and clad offset 5.1 inch TFT color LCD monitor with clear digital image display USB & VGA interface Software upgrade via USB interface Specifications: Model RY-F600 Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) Fiber cleaved length 10 ~16mm (Coating diameter<250µm);16mm(Coating diameter250~1000µm) Fiber diameter Cladding diameter:80 ~150µm , Coating diameter:100 ~1000µm Auto focusing Available Fiber aligning method Core aligning, clad aligning, manual aligning Average splice loss 0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB( NZDS) Splicing time Typical 9 sec,with standard SM fiber Heating time Typical 36 sec Applicable sleeves 60mm, 40mm and a series of micro sleeves Tension test 2N(option) Electrode life 5000 Battery capacity Typical 400 cycles (splice and heat) Monitor 5.1 inch TFT color monitor Terminal USB 1.1 and VGA, software upgrade via USB interface Operating condition 0 ~ 5000m above sea level, 0 ~ 95%RH and -10~50℃, respectively, Max. wind velocity of 15m/s Splicing mode Auto,normal Fiber cleaved angle threshold set 0.1 ~ 10.0℃ , 0.℃ step Power supply Li-battery 11.8V , AC100-240V DC12.6V/5.0A Dimension L169xW152xH155mm weight 2.4kg 2.9kg(battery) Package Include: 1 x Fusion Splicer Machine 1 x Power adapter 1 x Battery(Built-in) 1Pair x spare electrodes 1 x Cooling Tray 1 x user manual 1 x Carry Case 1 x Optical Fiber Cleaver 1 x Alcohol Box 1 x Tweezers 1 x Miller pliers 7 x Optical fiber fixture Payment Payment : We accept paypal Credit card payments must be made through PayPal. We recommend you to sign for a PayPal account before bidding. We will Not take responsible on Customs duty if any Shipping time : Shipping time : If you haven't get your parcel within the expected date,Pls contact with us directly.We can ensure solve it for you .Pls trust us .We need your support. Thanks .Yours Sincerely. Country Shipping Time Refund or Resend 80% 12% 5% United States United Kingdom Australia /Canada 10-20 working days 25 working days 27 working days >27 working days Singapore Other Asia country 15-25 working days 28 working days 32 working days >32 working days Germany /France Austria /Netherland Poland 20-30 working days 33 working days 36 working days >36 working days Spain Russia 25-35 working days 37 working days 40 working days >40 working days Others 25-35 working days 37 working days 40 working days >40 working days Feedback Feedback : We would appreciate receiving your 5 stars positive feedback.If there's any dissatisfaction with your parcel ,pls contact with us before you leave the feedback .We can solve it for your perfectly.Thanks for your understanding and help. Return Policy 1. All items are checked and packed in good condition before dispatch. 2. If you find any defect in our items, please contact us within 14 days of receipt item. 3. Return items must not be used. 4. Buyer is responsible for all return shipping charges. We will return all your money except the shipping and handling fees or make exchange for you after we receive your return items. Please do not ship the item back to us without our confirmation. Thanks Contact us SHIPPING TERMS: Our work time is during 8:00 am -5:30 pm ,from Monday to Friday (GMT+8 ).We will post your order within 24 hours (Except some special orders ,such as the handmade case). Maybe we are out of office during the weekend, so pls wait for our reply patiently. We will reply all your problems as quickly as we can. Thanks for your understanding. Engineered for professional eBay sellers!
