Ry-s1130d Qam 256 Catv Signal Level Meter

US $775.00

Zhejiang, China
Feb 23rd

Open on mobile:
QR code

RY-S1130D QAM 256 CATV Signal Level Meter Item Description RY-S1130D QAM 256 CATV Signal Level Meter Specifications FREQUENCY/ CHANNEL Frequency Range 5MHz ~ 870MHz Channel Range T7 to CATV 135 Frequency Resolution 10 KHz Measurement Randwidth 280 KHz MODULATION QAM Annex (A) 16, 32, 64, 128 and 256 QAM Annex (B)64 and 256 Symbol Rate 1 to 7Mbps Analog CATV AM, FM Bandwith 1 MHz to 9.9 MHz LEVEL MEASUREMENT Range -35dBmV ~ 60dBmV Accuracy +2dB Resolution 0.1 dB Scan peak value demodulation Input Impedance 75 CARRIER-NOISE RATIO - C/N Input Range 10dBmV ~45dBmV Accuracy +2 dBmV VOLTAGE MEASUREMENT Input Range 10 ~ 80V (AC/DC) Accuracy +2V Resolution 0.1V Technical indicators above @25oC POWER DC Supply 7.2V rechargeable battery AC Supply AC110V/60Hz +10% Working Time >4hrs (full charged battery) Charging Time <= 8hrs OTHER Dimensions 215mm x 3mm x 8mm Net Weight < 550g Temperature -10oC~45 oC Display 320 X 240 TFT LCD Audio Output Built-in speaker Digital or analog measurement available in one instrument Supports Annex A(16,32,64,128and256)and Annex B (64 and 256) QAM modes Leakage measurement in the spectrum mode or frequency mode if the exact frequency of the leakage is known All channel range from channel T7to135(5?C860MHz) Multi-function digital or analog signal analysis includes all pertinent channel and system-wide information Large, easy-to-read display provides quick glance capability in dimly lit environments High accuracy for all individual channel and system parameters including: spectrum, scan, tilt, carrier-to-noise, carrier level and line voltage measurements Tilt measurement for simplified system balancing MER, BER, Test constellation graphic display for accurate digital signal analysis Programmable power shut-off extends time between charges High impact plastic case and leatherette-vinyl case protect unit during field use Ordering Information RY-S1130DQ Supports Annex A(16,32,64,128and256)and Annex B (64 and 256) QAM modes RY-S1129D Annex A(16,32,64,128and256)and Annex B 64 QAM modes Customs duty Import Duties Customs taxes and charges are not included in the item price or shipping cost. These charges are the buyer’s responsibility. Export Duties Seller takes responsibility for export charges if there is . Payment We accept payment only through PAYPAL. Shipping General We ship products worldwide through standard express courier service and economy shipping service. Normally order would be shipped out with tracking# within 1-3 workdays after payment . Some customized products may take several days longer,please confirm. Delivery Time Expedited Shipping(FedEx/DHL/TNT/UPS):TO USA 3-6 Workdays ,TO Other countries 3-8 Workdays. EMS is also available,please don't hesitate to contact us if you need. Economy Shipping(e-Packet/Post/Airmail):TO USA 7-12 Workdays ,TO United Kingdom & Australia 20-35 Workdays , TO Other countries 20-50 Workdays. Sometimes Int'l delivery may be delayed because of some unexpected reason,such as bad weather, transportation accidents,customs issues and so on.If so,please don't hesitate to contact us.Thanks for kindly understanding. Delivery Address PO Boxes and APO/FPO addresses are mostly unacceptable for these express carrier from China.Please kindly make sure to provide correct,normal and detailed receiving address. It would be better to leave us your correct phone or telephone number,this way the express carrier can get in touch with you when package arrive and save much of your valuable time. Return Buyer's Problem We accept product return within 30 days after package received but product should be in original position and not in damaged condition,the return shipping charges will be buyers' responsibility. (This rule not apply to special customized products) Sellers's Problem We accept product return within 30 days after package received but product should be in original position and not in damaged condition,the return shipping charges will be seller's responsibility.(This rule apply to shipping wrong items and quality problem) Compensation Replacement or Refund at buyers' option. Feedback On Jan-29-15 at 03:25:04 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	NEW
Country/Region of Manufacture	China
Model	RY-S1130D
