S-100 Buss Breakout Board

US $15.00

  • Byron, California, United States
  • Mar 14th
 S-100 buss breakout board. Aids in the debug and testing of Legacy S100 computer boards. LED's for all three S100 bus voltages (+18, -18, -16) plus test pads. All S1-00 buss pins aligned at top of board with signal labels. Test points can be used for logic analyzer or logic probe. +5VDC connection for a logic probe, analyzer or similar. Completely assembled and tested.
New
Type Diagnostics
Country/Region of Manufacture United States
Brand Custom
