S89f1098 Honeywell Direct Spark Ignition Module Nib

US $79.95

Traverse City, Michigan, United States
Jan 29th

Open on mobile:
QR code

S89F1098Provide electronic control of direct spark ignition systems, with external spark transformers, used on gas-fired furnaces, boilers, conversion burners and other heating appliances. Features Controls ignition sequence and gas control operation in direct spark ignition systems. Control separate 120 Vac spark generator that provides high voltage potential for main burner ignition. Lockout after one trial for ignition if main burner fails to ignite. Reset from thermostat after lockout. Use separate electrodes for spark ignition and flame sensing. Use any 24 Vac combination gas control designed for direct spark applications and rated at 2.0A or less. Product Specifications Dimensions (in.)5 1/4 in. high x 4 1/16 in. wide x 1 15/16 in. longDimensions (mm)133 mm high x 103 mm wide x 49 mm deepElectrical Ratings24 VacFrequency60 HzApprovals, Canadian Standards AssociationDesign CertifiedFlame Failure Response Time (sec)2.0 sec. @ 2.5 microampPrePurge30 sec. minimumAmbient Temperature Range (F)-40 F to +175 FAmbient Temperature Range (C)-40 C to +79 CIgnition System TypeDirect Spark IgnitionIgnition SequenceSingle trial for main burner ignition (then shut down and lockout)Typical Gas ControlVR8205, VR8305Type of GasNatural or LPFlame SenseTwo RodIgnition SourceExternal (120 VAC powered) High Voltage Spark GeneratorIgnition Trials To Lockout1Lockout Timing4 sec.Ignition Trial Time (sec)4 sec.Maximum Valve Load @ 24 Vac (Amps)2AFlame Failure Re-ignition Time (sec)0.8 sec. maximum
