Sabertooth Dual 25a 6v-24v Regenerative Motor Driver

US $119.99

Swanton, Vermont, United States
Aug 17th

Open on mobile:
QR code

Description Dual motor controller - 25A 6V-24V Analog, R/C, simplified serial and packetized serial interfaces (TTL) Synchronous regenerative drive Ultra-sonic switching frequency (32kHz) Thermal and overcurrent protection Lithium protection mode The Sabertooth Dual 25A 6V-24V Regenerative Motor Driver is one of the most versatile, efficient and easy to use motor drivers on the market. It is suitable for high powered robots - up to 100lbs in combat or 300lbs for general purpose robotics. Out of the box, the Sabertooth can supply two brushed DC motors with up to 25A continuously. Peak currents of 50A per channel are achievable for a few seconds. Overcurrent and thermal protection means you'll never have to worry about killing the driver with accidental stalls or by hooking up a motor. Sabertooth allows you to control two motors with: analog voltage, radio control, serial and packetized serial. You can build many different robots of increasing complexity for years to come with a Sabertooth. Sabertooth has independent speed + direction operating modes, making it the ideal driver for differential drive (tank style) robots and more. The operating mode is set with the onboard DIP switches so there are no jumpers to lose. The Dimension Engineering Sabertooth Dual 25A Regenerative Motor Driver features screw terminal connectors - making it possible for you to build a robot without even soldering. Sabertooth is the first synchronous regenerative motor driver in its class. The regenerative topology means that your batteries get recharged whenever you command your robot to slow down or reverse. Sabertooth also allows you to make very fast stops and reverses - giving your robot a quick and nimble edge. Sabertooth has a built in 5V BEC that can provide power to a microcontroller or R/C receiver. The lithium cutoff mode allows Sabertooth to operate safely with lithium ion and lithium polymer battery packs - the highest energy density batteries available. Sabertooth's transistors are switched at ultrasonic speeds (32kHz) for silent operation. Applications: Combat robots up to 100lb Normal and hobby robots up to 300lb Differential drive robots Electric vehicles, ride-on toys, scooters Easy speed/direction control for pumps, conveyors, automation and any application that uses two brushed DC motors Specifications Input voltage: 6-24V nominal, 30V absolute max. Output current: 25A continuous, 50A peak. Size: 2.6x3.2x0.8" (65x80x20mm) Weight: 3.5oz (96g) Mounting hole configuration: 1.75x2.25"

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Dimension Engineering
Type	Dimension Engineering
MPN	Does not apply
UPC	Does not apply
