Saleae Logic 8 Logic Analyzer 8 Channels Black, US $4800 – Picture 0
Saleae Logic 8 Logic Analyzer 8 Channels Black, US $4800 – Picture 0

Saleae Logic 8 Logic Analyzer 8 Channels Black

US $4800

  • Verdun, Quebec, Canada
  • May 24th
Open on mobile:
QR code
TECHNICAL DETAILS Geometry and Weight Length & Width: 1.7 in (43.2mm) Thickness: .365 in (9.3mm) Volume: 1 in3 (16.4 cm3) Weight: .9 oz (25.5 gm) Inputs Input voltage range: -0.5V to 5.25V Input Low Voltage: -0.5V to 0.8V Input High Voltage: 2.0V to 5.25V Works with 5V, 3.3V, 2.5V, 2.0V systems. May work with 1.8V but not recommended. ESD protected per CE requirements Over-voltage protection to +/- 15V. Not meant for continuous operation outside -0.5V to 5.25V. Input Impedance: 1Mohm || 10pF (typical, approximate) Error/Accuracy: pulse-width measurement: +/- 42ns (at 24MHz). Sample Rate & Depth 24MHz. 16MHz, 12MHz, 8MHz, 4MHz, 2MHz, 1MHz, 500KHz, 250KHz, 200KHz, 100KHz, 50KHz, 25KHz; Note that achieving the highest sample rates requires low USB latency; this may not be achievable on all computers. Performance may improve with the removal of other USB devices, using a different USB host controller, or increasing the software's process priority. 10B samples. Absolute max depends on data compressibility, available RAM and operating system. 10B samples assumes reasonably high compressibility. System Requirements Windows XP (32-bit) Windows Vista (32-bit or 64-bit) Windows 7 (32-bit or 64-bit) Mac OS X 10.4 Tiger or higher Linux: recent Ubuntu, Fedora, or openSUSE. Other distributions are likely to work but not specifically supported. USB 2.0 What's in the Box Logic (fully tested) 1x9 Ultra-Flexible Test Lead Set x9 Micro Hook Clips USB Cable (2M length, A to mini-B) Custom Carrying Case

Directions
