Sampling-Probe Unit with Manual Tektronix Type 3S3, US $260 – Picture 0
Sampling-Probe Unit with Manual Tektronix Type 3S3, US $260 – Picture 0

Sampling-probe Unit With Manual Tektronix Type 3s3

US $260

  • Lewisville, Texas, United States
  • Jul 3rd
Open on mobile:
QR code
This Type 3S3 unit is in very good condition for its age. There are no noticeable nicks, chips or scratches. Includes protective sleeve and manual.   "The Tektronix Type 3S3 is a sampling plug-in for 560-series scopes. It requires P6038 probes which contain miniature sampling gates. The risetime is rated at 350 picoseconds. The sampling gates use four GaAs sampling diodes. The sampling pulse is produced by the Gate Generator module in the plug-in using a blocking oscillator driving a 152-115 step recovery diode and a 6.5 cm clipping line. Balanced pulses are sent up the cable to the sampling gate. The output of the sampling gate returns to the plug-in through the same cable, and enters the preamp. The same blocking oscillator that generates the sampling pulses also generates the strobe for the memory circuit. The sampling efficiency is specified to be 2%. The 3S3 is recommended in the Type 111 manual for checking the output pulse risetime. The 3S3 has a main chassis and sub-chassis that plug into it. There is a sub-chassis extension, part number 012-077, that allows maintenance of the sub-chassis." No means to test unit -- sold AS-IS ------------------------------------------------------------------------------------------------------------------ Payment Policy: We accept PayPal (via Ebay) Shipping: USA:  We use UPS or FedEx  Ground as standard shipping method for all 48 States.  Ebay GSP is used for limited international shipping.  See below. International Shipping: LIMITED INTERNATIONAL SHIPPING      INCLUDES:  Canada, United Kingdom, Denmark, Finland, Greece, Japan, Sweden, Belgium,                             France, Ireland, Netherlands, Spain, Italy, Germany, Austria, Israel,                             Mexico, Switzerland, Norway, Bermuda, South Korea, Taiwan Returns Policy: Our goal is to ensure you are completely satisfied with your purchase. Please Read carefully the description of the item listed for full details before bidding.   No returns or exchanges are accepted. -------------------------------------------------------------------------------------------------------------------
“In very good cosmetic condition-with protective cardboard sleeve. Not tested. Manual is included.”
Country/Region of Manufacture United States
Product Type 3S3
Brand Tektronix
ISBN Does not apply
