Scallop Imaging D7-180 Security Camera 180 Degree View 7mp

US $1,199.00

Mesa, Arizona, United States
Jan 30th

Open on mobile:
QR code

The D7 is a seven megapixel surveillance camera that records in full-color high resolution throughout its 180° field of view, without fish-eye distortion. At all times the D7-180 Vision System is processing over 100 megapixels per second providing a 180° full situational awareness image, plus up to four zoom windows. D7-180 | Specifications Image Device: 5 x 1.3 Mpixel CMOS Number of effective pixels: 6,553,600 pixels Shutter: Electronic rolling shutter Gain Control: Automatic gain control Exposure control: Average, 5 zone independent Depth of Field: 1? to infinity Minimum illumination: .5 lux Image size (HxV): 2 simultaneous video streams: A standard 15 fps High Definition (HD) frame comprised of a 1280 x 320 situational awareness (SA) window plus a 1280 x 400 sub window allocated to up to four zoom windows; 5120 x1280 full resolution stream at 3 fpsThe video stream image is displayed at up to 15 fps, providing the full 180 degree situational awareness and up to four independent zoom windows. The zoom windows are derived from the full resolution stream for up to 4x zoom effect. HD Window:Full Res Image:Field of view: 180 degrees x 48 degrees 28 pixels per degree of field of view Image resolution: Everywhere within the field of view equivalent to resolution of a 1.3 MP camera with a 33.7mm lens Compression: H.264 Maximum frame rate: 15 fps for SA and zoom, 3 fps for full resolution window Compression ratio: User selectable Bandwidth requirements using H.264 at good quality compression: At 15 fps, less than 2.0 Mbit/sec At 3 fps, less than 3 Mbit/sec Minimum System Requirements: Windows® 7, Windows 8 2.0 GHz CPU (Dual-core 1.8GHz or higher CPU with 2 GB RAM or higher recommended) 2 GB RAM or higher 200 MB hard drive space 256 MB or higher video memory Minimum display resolution 1280 x 1024 10/100 Mb Ethernet adapter POE Switch or 12V power supply (available from Scallop Imaging) Internet Explorer or Mozilla FireFox Network Protocols: TCP/IP, HTTP, SMTP, DHCP, RTP/RTSP (Currently), DNS, BONJOUR Interface: Internet Explorer, Firefox Ethernet: 10Base-T/100Base COMM ports: Ethernet General: Weight: 9 oz. (255 g) Dimensions (WxHxD): 3.28 x 5.72 x 2.49 inches (83 x 145 x 63 mm) Power requirements: 48V PoE, 12V DC Power consumption: < 7 W Operating temp.: -40 degrees F to 140 degrees F (-40 degrees C to 60 degrees C) Storage temperature: -40 degrees F to 185 degrees F (-40 degrees C to 85 degrees C) Supplied Accessories: flush mount, surface mount, angle mount kit Warranty: 24 months (subject to standard terms and conditions)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Scallop Imaging
Model	D7-180
